GPU Compute — NVIDIA and Intel

Two GPU stories converged on the same cluster, and neither was straightforward.

The NVIDIA side started with a card that booted fans and RGB but refused to appear on the PCIe bus. The RTX 5070 was physically installed, powered, seated — and completely invisible to the kernel. Diagnostics showed no vendor ID, no BAR regions, no device of any kind. The software stack was ready and waiting; the hardware just would not cooperate.

The Intel side was a different kind of challenge. The three mini nodes each have an integrated Arc GPU that shares system RAM. These are not suitable for LLMLarge Language ModelA model trained to predict text, served behind a chat or completion endpoint. On Frank these run locally on the GPU node rather than against a hosted provider. inference (memory bandwidth is the bottleneck), but they are perfect for media transcoding and vision workloads. The catch: Kubernetes 1.35 had removed the v1beta1 DRADynamic Resource AllocationThe Kubernetes API for requesting specialised hardware — GPUs and accelerators — with far more expressiveness than the older device-plugin counter model. API that the upstream Intel driver chart depended on. Every chart template needed patching before it would work.

Both paths required Talos extensions, kernel-level config, and some chart surgery. This post walks through both.

    flowchart LR
  subgraph NVIDIA[NVIDIA RTX 5070]
    Ext1[Talos extensions<br/>nvidia-container-toolkit<br/>nvidia-open-gpu-kernel]
    Mods[Kernel modules<br/>nvidia, nvidia_uvm]
    Op[GPU Operator<br/>Helm chart v25.10.1]
    HW[Hardware saga<br/>reseat fixed invisibility]
  end
  subgraph Intel[Intel Arc iGPU]
    Ext2[Talos extensions<br/>i915, intel-ucode]
    CDI[CDI containerd config<br/>/var/cdi instead of /etc]
    Chart[Vendored chart<br/>patched for K8s 1.35]
    DRA[DRA pipeline<br/>ResourceSlice → DeviceClass → Claim]
  end

  Ext1 --> Mods --> Op --> HW
  Ext2 --> CDI --> Chart --> DRA


Part 1: NVIDIA GPU Operator

The plan for gpu-1 was straightforward: install NVIDIA’s Talos extensions, load the kernel modules, deploy the GPU Operator via Helm, and start scheduling CUDACompute Unified Device ArchitectureNVIDIA's GPU programming platform. Practically, the layer every local inference engine sits on, and the reason a driver/toolkit version mismatch stops a model loading. workloads. The infrastructure side worked. The hardware had other ideas.

Talos Extensions for NVIDIA

Talos Linux uses a read-only, immutable root filesystem. You cannot apt install or modprobe anything at runtime. Instead, you bake system extensions into the node’s image. For NVIDIA, two extensions are required:

• nvidia-container-toolkit-production — container runtime hooks for GPU access
• nvidia-open-gpu-kernel-modules-production — open-source NVIDIA kernel driver

On Omni, you declare extensions per machine:

# patches/phase04-gpu/402-gpu1-nvidia-extensions.yaml
metadata:
    type: ExtensionsConfigurations.omni.sidero.dev
    id: 402-gpu1-nvidia-extensions
    labels:
        omni.sidero.dev/cluster: frank
        omni.sidero.dev/cluster-machine: 03ff0210-...
spec:
    extensions:
        - siderolabs/iscsi-tools
        - siderolabs/nvidia-container-toolkit-production
        - siderolabs/nvidia-open-gpu-kernel-modules-production

A critical gotcha: per-machine ExtensionsConfiguration resources in Omni override the cluster-wide config entirely — they do not merge. If the cluster already has iscsi-tools (needed for Longhorn), you must re-include it in the per-machine config or gpu-1 will lose iSCSI support.

Applying the extension triggers an image rebuild and a reboot. Once the node comes back, the second patch loads the kernel modules:

# patches/phase04-gpu/04-gpu-nvidia-modules.yaml
spec:
    data: |
        machine:
            kernel:
                modules:
                    - name: nvidia
                    - name: nvidia_uvm
                    - name: nvidia_modeset
                    - name: nvidia_drm

Ordering matters: extensions must be in the image schematic before you try to load the modules. Apply the extension config first, wait for Ready, then apply the module patch.

GPU Operator Helm Values

With the driver and toolkit baked into Talos, the GPU Operator’s job shrinks. Most of its default components would try to install what Talos already provides:

# apps/gpu-operator/values.yaml
driver:
  enabled: false

toolkit:
  enabled: false

operator:
  defaultRuntime: containerd

driver.enabled: false because Talos provides the kernel modules. toolkit.enabled: false because Talos provides the container toolkit. The operator still handles device discovery, the device plugin, GPU feature discovery, and the DCGMData Center GPU ManagerNVIDIA's GPU telemetry daemon. It is what exports utilisation, memory and temperature to Prometheus so a GPU node can be observed like any other. exporter — all the Kubernetes-level plumbing.

The ArgoCD Application uses NVIDIA’s official Helm chart at v25.10.1:

# apps/root/templates/gpu-operator.yaml
spec:
  sources:
    - repoURL: https://helm.ngc.nvidia.com/nvidia
      chart: gpu-operator
      targetRevision: "v25.10.1"
      helm:
        valueFiles:
          - $values/apps/gpu-operator/values.yaml
  syncPolicy:
    # Manual sync — GPU hardware not yet detected

Notice the sync policy: no automated block. This was intentional, and brings us to the hardware saga.

The Hardware Saga

The RTX 5070 is physically installed in gpu-1. The Gigabyte Z790 Eagle AX motherboard has a PCIe 5.0 x16 slot. The card is seated, powered (dual 8-pin), and the fans spin on boot. The RGB on the case fans works fine.

Initially, the card was completely invisible to the PCIe bus — lspci showed nothing, no NVIDIA vendor ID 10de, silence. The NVIDIA kernel modules would load without error and simply find no hardware to bind to. The GPU Operator deployed fine from a software perspective, but there was no GPU to operate on.

What was tried before the fix:

• BIOS settings — confirmed PCIe set to Auto/Gen5, CSM disabled, Above 4G Decoding enabled, Resizable BAR enabled.
• Different BIOS versions — updated from the factory BIOS (predating RTX 50-series) to the latest available. No change.
• Power supply — verified PSU rail stability with a multimeter on the PCIe power connectors.

The fix: reseating the card. Removing and firmly reinstalling the RTX 5070 in the x16 slot resolved the detection issue. The connection was making just enough contact to power the fans but not enough to establish PCIe signaling.

$ talosctl -n 192.168.55.31 dmesg | grep "0000:01:00.0"
pci 0000:01:00.0: [10de:2c05] type 00 class 0x030000 PCIe Legacy Endpoint
pci 0000:01:00.0: BAR 1 [mem 0x4800000000-0x4bffffffff 64bit pref]
pci 0000:01:00.0: 32.000 Gb/s available PCIe bandwidth, limited by 2.5 GT/s PCIe x16 link
pci 0000:01:00.0: vgaarb: setting as boot VGA device

Vendor ID 10de confirms the RTX 5070 is now visible. One quirk: the link negotiates at 2.5 GT/s (PCIe Gen 1) rather than 32 GT/s (Gen 5). This is a known issue with some Z790 boards and the RTX 50-series requiring a BIOS update to negotiate Gen 5 properly. For compute-bound workloads, the GPU runs at full speed regardless.

$ talosctl -n 192.168.55.31 dmesg | grep NVRM
NVRM: loading NVIDIA UNIX Open Kernel Module for x86_64  570.211.01

$ kubectl get node gpu-1 --show-labels | tr ',' '\n' | grep nvidia
extensions.talos.dev/nvidia-container-toolkit-production=570.211.01-v1.18.2
extensions.talos.dev/nvidia-open-gpu-kernel-modules-production=570.211.01-v1.12.4
nvidia.com/gpu.present=true

After the fix, the ArgoCD Application was updated to automated sync:

syncPolicy:
  automated:
    prune: false
    selfHeal: true

$ POD=$(kubectl get pod -n gpu-operator -l app=nvidia-dcgm-exporter -o jsonpath="{.items[0].metadata.name}"); kubectl exec -n gpu-operator "$POD" -c nvidia-dcgm-exporter -- nvidia-smi
Mon Apr 20 17:23:30 2026
+-----------------------------------------------------------------------------------------+
| NVIDIA-SMI 570.211.01             Driver Version: 570.211.01     CUDA Version: 12.8     |
| GPU  Name                 Persistence-M | Bus-Id          Disp.A | Volatile Uncorr. ECC |
|   0  NVIDIA GeForce RTX 5070 Ti     Off |   00000000:01:00.0 Off |                  N/A |
|  0%   33C    P8             19W /  300W |    7956MiB /  16303MiB |      0%      Default |
+-----------------------------------------------------------------------------------------+

Part 2: Intel Arc iGPU via DRA

The three mini nodes each have an Intel Core Ultra with an integrated Intel Arc GPU. These share system RAM instead of having dedicated VRAMVideo RAMMemory on the GPU itself. Both the model weights and the KV cache live here, which makes it the binding constraint on what a single card can serve. — unsuitable for LLM inference, but excellent for hardware video transcode (Quick Sync), computer vision via OpenVINO, and OpenCL compute. More importantly, they gave us a reason to implement DRA — the replacement for the Kubernetes device plugin model.

Why DRA Over Device Plugins

Kubernetes device plugins (since v1.10) expose hardware through opaque integers in resources.limits — nvidia.com/gpu: 1. It works, but it has limitations that become painful as hardware diversity grows:

• Devices are integers — you cannot express “I want a GPU with at least 4GB VRAM” or “same NUMANon-Uniform Memory AccessOn multi-socket machines, memory attached to one CPU is slower to reach from another. Ignoring the topology costs real throughput. node as my CPU.”
• Allocation is first-come-first-served with no structured claim semantics.
• No standard way for a device to be shared between containers in a pod.

Dynamic Resource Allocation (DRA), GA in Kubernetes 1.32, uses resource.k8s.io/v1 and introduces three concepts:

ResourceSlice — Published by the driver on each node. It advertises available devices with structured attributes (device model, memory, features). Unlike a device plugin’s flat integer, the slice carries enough information for the scheduler to match against capability requirements.

DeviceClass — A cluster-wide object that selects devices using CELCommon Expression LanguageA small, safe expression language for evaluating conditions inside configuration. Tekton's triggers use it to decide whether an incoming webhook should start a pipeline. expressions:

apiVersion: resource.k8s.io/v1
kind: DeviceClass
metadata:
  name: gpu.intel.com
spec:
  selectors:
  - cel:
      expression: device.driver == "gpu.intel.com"

ResourceClaim — The pod-side object. Instead of resources.limits, the pod declares a claim referencing the DeviceClass. The scheduler finds a matching device, binds the claim, and the kubelet plugin injects it via CDIContainer Device InterfaceA vendor-neutral spec for describing a device — a GPU, say — so a container runtime can inject it without a bespoke plugin per vendor..

apiVersion: v1
kind: Pod
metadata:
  name: gpu-test
spec:
  containers:
  - name: test
    image: ubuntu
    command: ["ls", "-la", "/dev/dri/"]
    resources:
      claims:
      - name: gpu
  resourceClaims:
  - name: gpu
    deviceClassName: gpu.intel.com

i915 Extensions on Talos

The Intel Arc iGPU needs the i915 kernel driver and updated microcode. On Talos, these come as system extensions:

# patches/phase05-mini-config/500-mini1-i915-extensions.yaml
metadata:
    type: ExtensionsConfigurations.omni.sidero.dev
    id: 500-mini1-i915-extensions
spec:
    extensions:
        - siderolabs/iscsi-tools
        - siderolabs/i915
        - siderolabs/intel-ucode

The same iscsi-tools gotcha applies: per-machine extension configs override the cluster-wide list. Re-include it.

There are three separate files — one per mini node — because all three are control-plane members. Applying an extension triggers a reboot. Apply all three simultaneously and you lose quorum. The safe sequence is serial:

omnictl apply -f patches/phase05-mini-config/500-mini1-i915-extensions.yaml
kubectl get node mini-1 -w   # wait for Ready

omnictl apply -f patches/phase05-mini-config/501-mini2-i915-extensions.yaml
kubectl get node mini-2 -w   # wait for Ready

omnictl apply -f patches/phase05-mini-config/502-mini3-i915-extensions.yaml
kubectl get node mini-3 -w   # wait for Ready

CDI Containerd Configuration

DRA drivers inject devices into containers using the Container Device Interface (CDI). The Intel driver writes a CDI spec file to a directory on the host, and containerd reads it when starting a container. By default, the driver writes to /etc/cdi/.

On Talos, /etc is part of the read-only root filesystem. Writes to /etc/cdi/ silently fail. The fix: tell both containerd and the driver to use /var/cdi/ instead, since /var is writable:

# patches/phase05-mini-config/05-mini-cdi-containerd.yaml
spec:
    data: |
        machine:
            files:
                - path: /etc/cri/conf.d/20-customization.part
                  op: create
                  content: |
                      [plugins."io.containerd.cri.v1.runtime"]
                        cdi_spec_dirs = ["/var/cdi/static", "/var/cdi/dynamic"]

Talos supports containerd config drop-ins at /etc/cri/conf.d/. Writing a customization part overrides the CDI spec directories without modifying the main containerd config. Containerd restarts automatically when this file appears — no node reboot required.

Chart Vendoring for K8s 1.35

The Intel GPU resource driver’s official Helm chart was built for Kubernetes 1.32-1.34. Our cluster runs Kubernetes 1.35, which removed the resource.k8s.io/v1beta1 API. The upstream chart uses v1beta1 for its DeviceClass and ValidatingAdmissionPolicy.

Rather than maintaining Kustomize overlays or post-render hooks, I vendored the chart into the repo and patched it directly at apps/intel-gpu-driver/chart/ with version 0.7.0-k8s135. Five patches were needed:

1. DeviceClass API version — v1beta1 to v1:

apiVersion: resource.k8s.io/v1

2. ValidatingAdmissionPolicy — policy API version and ResourceSlice API version:

apiVersion: admissionregistration.k8s.io/v1
spec:
  matchConstraints:
    resourceRules:
    - apiGroups:   ["resource.k8s.io"]
      apiVersions: ["v1"]
      resources:   ["resourceslices"]

3. Namespace PSAPod Security AdmissionThe built-in gate enforcing pod security standards per namespace. Frank labels namespaces `privileged` where hostPort or privileged pods are genuinely required. label — the DRA driver DaemonSet uses hostPath volumes. Pod Security Admission blocks this by default:

metadata:
  labels:
    pod-security.kubernetes.io/enforce: privileged

4. CDI hostPath — changed from /etc/cdi to /var/cdi/dynamic:

volumes:
- name: cdi
  hostPath:
    path: /var/cdi/dynamic

5. Image update — upstream used Docker Hub v0.7.0. Updated to GHCRGitHub Container RegistryGitHub's OCI registry at `ghcr.io`. Where Frank's CI-built images are published before ArgoCD rolls them out. v0.9.1 with resource.k8s.io/v1 support:

image:
  repository: ghcr.io/intel/intel-resource-drivers-for-kubernetes
  name: intel-gpu-resource-driver
  tag: "v0.9.1"

Verifying It Works

$ kubectl get pods -n intel-gpu-resource-driver -o wide
NAME                                            READY   NODE
intel-gpu-resource-driver-kubelet-plugin-xxxxx   1/1    mini-1
intel-gpu-resource-driver-kubelet-plugin-yyyyy   1/1    mini-2
intel-gpu-resource-driver-kubelet-plugin-zzzzz   1/1    mini-3

$ kubectl get resourceslice -o wide
NAME                       DRIVER         NODE
mini-1-gpu-intel-com-...   gpu.intel.com  mini-1
mini-2-gpu-intel-com-...   gpu.intel.com  mini-2
mini-3-gpu-intel-com-...   gpu.intel.com  mini-3

$ kubectl get deviceclass
NAME            AGE
gpu.intel.com   2d

A smoke-test pod that claims a GPU and lists DRI devices:

apiVersion: v1
kind: Pod
metadata:
  name: gpu-smoke-test
spec:
  containers:
  - name: test
    image: ubuntu:24.04
    command: ["ls", "-la", "/dev/dri/"]
    resources:
      claims:
      - name: gpu
  resourceClaims:
  - name: gpu
    deviceClassName: gpu.intel.com
  restartPolicy: Never

$ kubectl logs gpu-smoke-test
crw-rw---- 1 root video 226,   0 Mar  4 ... /dev/dri/card0
crw-rw---- 1 root render 226, 128 Mar  4 ... /dev/dri/renderD128

Both card0 (display) and renderD128 (compute/render) are present. The GPU is accessible through the DRA pipeline: ResourceSlice advertised the device, DeviceClass matched it, ResourceClaim requested it, the kubelet plugin injected it via CDI.

What We Have Now

• Intel Arc iGPU exposed on mini-1/2/3 via DRA (ResourceSlice → ResourceClaim)
• NVIDIA RTX 5070 detected and operational on gpu-1, GPU Operator with automated sync
• GPU-local Longhorn storage on gpu-1 for AI workloads
• Vendored Intel driver chart patched for K8s 1.35, no upstream dependency

Missteps

References

• NVIDIA GPU Operator — Automated GPU management in Kubernetes
• NVIDIA GPU Support on Talos Linux — Talos extensions for NVIDIA
• Kubernetes Dynamic Resource Allocation — ResourceSlice, DeviceClass, ResourceClaim
• Intel Resource Drivers for Kubernetes — DRA-based GPU resource driver
• Container Device Interface (CDI) — CNCFCloud Native Computing FoundationThe foundation that hosts Kubernetes and most of the projects around it. "CNCF project" is a statement about governance, not quality or maturity. specification for runtime device injection
