Workflow Automation with n8n

The cluster can reason, orchestrate, and generate media. But most real work is a chain of steps — fetch from an API, transform, call an LLMLarge Language ModelA model trained to predict text, served behind a chat or completion endpoint. On Frank these run locally on the GPU node rather than against a hosted provider., post the result, repeat on a schedule. That is workflow automation.

n8n is an open-source workflow automation platform with 400+ integrations, a visual node editor, and a webhook system. It runs as a single Node.js process backed by PostgreSQL.

    flowchart LR
  subgraph Authentik[Authentik — Forward Auth Proxy]
    BP[Blueprint ConfigMap<br/>forward_single proxy]
  end
  subgraph GPU1[gpu-1 — i9, 128GB RAM]
    subgraph n8nInstance[n8n-01 — per-user instance]
      n8n[n8n Deployment<br/>port 5678]
      PVC[10Gi PVC<br/>Longhorn<br/>/home/node/.n8n]
    end
    DB[paperclip-db-postgresql<br/>Bitnami PostgreSQL<br/>5Gi Longhorn]
  end
  subgraph Network
    LB[Service<br/>192.168.55.216:5678<br/>Cilium L2]
    Metrics[Prometheus /metrics<br/>scraped by VMAgent → Grafana]
  end

  BP -->|forward-auth| n8n
  n8n -->|DATABASE_URL| DB
  n8n --> Metrics
  LB --> n8n


Why Per-User Instances

n8n’s Community Edition does not support multi-user accounts with workflow isolation. SSOSingle Sign-OnOne login across many applications. On Frank, Authentik holds the session and Traefik asks it before forwarding a request. (OIDCOpenID ConnectAn identity layer on top of OAuth 2.0: it adds a token saying *who* the user is, not merely what the client may do. Frank's single sign-on speaks it, with Authentik as the provider./SAMLSecurity Assertion Markup LanguageThe XML-based single sign-on standard that predates OIDC. Still what many enterprise applications support, and only that.) is enterprise-only, gated behind a $400/month license. The pattern is simple: n8n-01, n8n-02, n8n-03 — each with its own namespace, PostgreSQL, PVCPersistentVolumeClaimA Kubernetes request for durable storage. The pod names a claim and the storage layer — Longhorn on Frank — binds real disk behind it, so the data outlives the pod., and LoadBalancer IP. Adding an instance is a find-replace across ~6 files.

Why gpu-1

Not for the GPU — n8n does not request nvidia.com/gpu. gpu-1 has an i9 and 128GB RAM sitting mostly idle while Ollama and ComfyUI take turns with the RTX 5070. n8n tolerates the GPU taint but does not claim GPU resources.

Architecture

Two ArgoCD apps per instance:

Authentication: The OIDC Detour

n8n Community Edition gates OIDC behind enterprise. A community project (n8n-oidc) injects OIDC via external hooks — but no commits in three months and open issues with zero maintainer response.

The solution: Authentik forward-auth proxy, same pattern as Longhorn, Hubble, and Sympozium. A blueprint ConfigMap in authentik-extras:

- model: authentik_providers_proxy.proxyprovider
  identifiers:
    name: n8n-01
  attrs:
    mode: forward_single
    external_host: https://n8n-01.frank.derio.net

The Init Container That Wasn’t

The plan included an init container to bootstrap the admin account via n8n user:create. Community forums suggested this would work. It didn’t — n8n Community Edition has no user:create CLI command. The owner account must be created via the browser setup wizard on first access.

Secrets and Encryption

Three values in the SOPSSecrets OPerationSMozilla's tool for encrypting the *values* in a YAML file while leaving the keys readable, so an encrypted secret still reviews as a sensible diff.-encrypted secret secrets/n8n-01/n8n-01-secrets.yaml:

The encryption-key is critical. n8n uses it to encrypt stored API credentials. Without it set explicitly, n8n auto-generates one on the filesystem — lose the PVC, lose all credentials.

Metrics

n8n exposes Prometheus metrics at /metrics with N8N_METRICS=true:

annotations:
  prometheus.io/scrape: "true"
  prometheus.io/port: "5678"
  prometheus.io/path: "/metrics"

VMAgent auto-discovers these and feeds execution counts, durations, error rates into VictoriaMetrics → Grafana.

Adding Instances

1. Copy apps/n8n-01/ → apps/n8n-<NN>/, find-replace n8n-01 → n8n-<NN>
2. Copy apps/n8n-01-postgresql/ → apps/n8n-<NN>-postgresql/, find-replace
3. Copy the 3 Application CRCustom ResourceAn object of a type Kubernetes did not ship with, added by a CRD. Frank's ArgoCD Applications, Rollouts and Tekton Pipelines are all CRs. templates, find-replace
4. Pick next available IP from 192.168.55.2xx range
5. Add proxy provider to blueprints-proxy-providers.yaml
6. Create and encrypt secrets/n8n-<NN>-secrets.yaml
7. Apply SOPS secret, commit, push

Missteps

Recovery Path

References

• n8n documentation — Hosting, environment variables, community features
• Bitnami PostgreSQL chart
• Authentik proxy providers
