Edge Observability — Watching Frank's Edge Without Watching Frank's Edge Burn

The blog at blog.derio.net/frank had no observability. Hop is a single Hetzner CX23 with 4 GB RAM and no Grafana. Caddy’s stdout had the answer to every question — nothing was reading it.

This post covers the full edge observability stack: collectors on Hop, backend on Frank, four phases of deployment with the gotchas that came with each.

Architecture

    flowchart TD
  subgraph Hop[Hop — CX23, 4 GB]
    C[Caddy — blog.derio.net<br/>JSON access logs]
    FB[fluent-bit DaemonSet<br/>/var/log/containers → VL]
    CS[CrowdSec agent + LAPI<br/>HTTP scenarios + bouncer]
    F[Falco — modern_ebpf<br/>runtime security]
  end
  subgraph Frank[Frank — homelab]
    VL[victoria-logs<br/>LB 192.168.55.225:9428]
    GC[goatcounter<br/>LB 192.168.55.224:8080]
    AA[ai-alert-helper<br/>LiteLLM → Telegram]
    GR[Grafana — 3 dashboards]
  end
  subgraph Internet
    HV[Hugo blog JS snippet<br/>→ counter.derio.net]
  end
  C -->|stdout| FB
  FB -->|Loki push protocol| VL
  CS -->|decisions| VL
  F -->|Loki push protocol| VL
  HV -->|reverse proxy| GC
  VL --> GR
  GR -->|webhook| AA
  AA -->|Telegram bot| TG[Telegram — @agent_zero_cc_bot]


Three cross-cluster networking facts the design is built on:

• Tailscale subnet router advertises only home-LAN CIDRsClassless Inter-Domain RoutingThe `10.0.0.0/8` notation for an address range — the number after the slash is how many leading bits are fixed. Pod, service and LoadBalancer ranges are all expressed this way. — not the kube service CIDR. Cross-cluster reach goes via Cilium L2 LoadBalancer IPs in 192.168.55.x.
• Frank has no Alertmanager — alerting is entirely Grafana-managed.
• Grafana lives as a subchart of victoria-metrics — no apps/grafana/values.yaml.

Phase 1 — Log Plumbing

Extend the existing VictoriaLogs. Frank already had apps/victoria-logs/ with 14d retention, 20Gi PVCPersistentVolumeClaimA Kubernetes request for durable storage. The pod names a claim and the storage layer — Longhorn on Frank — binds real disk behind it, so the data outlives the pod.. Bump retention to 30d, add a sibling LoadBalancer Service at 192.168.55.225 via the chart’s extraObjects:

extraObjects:
  - apiVersion: v1
    kind: Service
    metadata:
      name: victoria-logs-lb
      annotations:
        lbipam.cilium.io/ips: "192.168.55.225"
    spec:
      type: LoadBalancer
      selector:
        app.kubernetes.io/name: victoria-logs-single
      ports:
        - { name: http, port: 9428, targetPort: 9428 }

On Hop, mirror the existing fluent-bit pattern — same chart, same kubernetes filter, different destination:

[OUTPUT]
    Name            http
    Match           kube.*
    Host            192.168.55.225
    Port            9428
    URI             /insert/jsonline?_stream_fields=stream,kubernetes.pod_name,kubernetes.namespace_name,kubernetes.container_name&_msg_field=msg&_time_field=time
    Format          json_lines

The first version shipped with _msg_field=log — wrong. Caddy emits {"msg": "handled request", ...} at the top level. VictoriaLogs helpfully returns _msg: "missing _msg field". Fix: _msg_field=msg.

Hop’s monitoring namespace needs pod-security.kubernetes.io/enforce: privileged for fluent-bit’s hostPath mount to /var/log/containers.

Caddy’s log directive must be inside each site block, not global. The global log sets the runtime/error logger. Access logs are per-site, opt-in.

Phase 2 — Blog Analytics

GoatCounter over Umami. GoatCounter is a single Go binary with SQLite, fits in 40 MB, no Postgres companion.

Kubernetes auto-injects GOATCOUNTER_PORT=tcp://10.x.x.x:8080 when a Service named goatcounter exists — pod crashloops reading tcp://... as port number. enableServiceLinks: false on the Pod spec fixes it.

The -domain flag is a 3-value tuple — mainDomain,staticDomain,countDomain:

args:
  - serve
  - -db=sqlite+/home/goatcounter/data.sqlite3
  - -listen=:8080
  - -tls=none
  - -domain=counter.cluster.derio.net,counter.cluster.derio.net,counter.derio.net

The Hugo snippet drops in blog/layouts/partials/custom/goatcounter.html, guarded by hugo.Environment == "production" so dev builds do not pollute counts.

Authentik blueprint for counter.cluster.derio.net — same manual outpost assignment pattern as every other forward-auth service.

Phase 3 — Edge Security with CrowdSec

CrowdSec runs as agent + LAPILocal APICrowdSec's local decision service. Agents report parsed events to it and bouncers ask it who to block — which means if its database is ephemeral, the whole ban pipeline silently does nothing.. The agent tails Caddy logs, applies HTTP behavioral scenarios, writes ban decisions to LAPI. The Caddy bouncer module polls LAPI every 10s and returns 403 for banned IPs.

Build requires Go 1.25.7+ for caddy-crowdsec-bouncer v0.12.1 — bumped Caddy from 2.9 to 2.11.3:

FROM caddy:2.11.3-builder AS builder
RUN xcaddy build \
    --with github.com/caddy-dns/cloudflare \
    --with github.com/hslatman/caddy-crowdsec-bouncer/http

Caddy bouncer config references crowdsec-service (not crowdsec-lapi — the chart names the Service differently than the spec assumed):

crowdsec {
  api_url http://crowdsec-service.crowdsec-system.svc:8080
  api_key {env.CROWDSEC_BOUNCER_API_KEY}
  ticker_interval 10s
}

LAPI Persistence Problem

Hop has no persistent volume available for CrowdSec — both existing PVsPersistentVolumeThe actual piece of storage a PVC binds to. The claim is the request; the PV is what satisfies it. are bound. Without persistence, each LAPI restart wipes the bouncer registration, causing the Caddy bouncer to get access forbidden in a tight retry loop.

Fix: a postStart hook that re-registers the bouncer with a fixed key:

lifecycle:
  postStart:
    exec:
      command:
        - /bin/sh
        - -c
        - |
          for i in $(seq 1 10); do
            cscli bouncers list >/dev/null 2>&1 && break
            sleep 2
          done
          cscli bouncers add caddy-hop -k "$CADDY_HOP_BOUNCER_KEY" 2>/dev/null

The postStart hook was treating a symptom, not the root cause. The CrowdSec agent is a separate machine registered in LAPI’s SQLite DB — every LAPI restart also wiped the agent’s machine row, so the still-running agent crashlooped (ent: machine not found), parsing zero Caddy logs. Two bugs stacked: the crashloop hid the parser misconfiguration (container_runtime: docker instead of containerd for Talos’s CRIContainer Runtime InterfaceThe contract between the kubelet and whatever actually runs containers — containerd on Talos. It also decides the log format on disk, which is why CrowdSec has to be told which runtime it is parsing. format). The dashboard was green through both.

Fix for both: persist LAPI onto a static PV backed by the existing Hetzner Volume subdirectory:

spec:
  storageClassName: hetzner-volume
  claimRef:
    namespace: crowdsec-system
    name: crowdsec-db-pvc
  hostPath:
    path: /var/mnt/hop-data/crowdsec/data
    type: DirectoryOrCreate

After the switch, rollout restart daemonset/crowdsec-agent to re-register against the fresh persistent DB. One line to fix the parser: container_runtime: containerd.

Phase 4 — Falco on Talos

Falco DaemonSet with driver.kind: modern_ebpf — the only viable driver on Talos (no kernel headers). Default rules do not reliably catch kubectl exec on Talos, but container CVECommon Vulnerabilities and ExposuresThe public catalogue of known security flaws, each with an identifier like `CVE-2024-3094`. A CVE number is an index entry, not a severity. classes (cryptominer exec, suspicious file reads, DNS exfil) do trigger.

Falcosidekick sends to Loki output (VictoriaLogs natively accepts Loki push protocol at /insert/loki/api/v1/push) and Telegram for critical events:

falcosidekick:
  config:
    loki:
      hostport: "http://192.168.55.225:9428"
      endpoint: "/insert/loki/api/v1/push"
    telegram:
      minimumpriority: "critical"

The macro override pattern in Falco: re-declare the macro with the same name in a later-loaded rules file. No override: key exists:

customRules:
  talos-quiet.yaml: |-
    - macro: user_known_shell_in_container_activities
      condition: (k8s.ns.name = "kube-system")

Phase 5 — AI Alert Helper

A Python FastAPI service with two functions:

1. Daily digest — summarizes the previous day’s blog traffic into a ~200-word Telegram narrative.
2. Alert enrichment — receives Grafana webhooks, adds LLMLarge Language ModelA model trained to predict text, served behind a chat or completion endpoint. On Frank these run locally on the GPU node rather than against a hosted provider.-generated context before routing to Telegram.
3. Surge detection — compares current traffic to historical baseline, classifies anomalies.

The fact-sheet contract is the swap point:

def summarize(facts: dict) -> str:
    """Daily digest — ~200-word narrative from structured facts dict."""

def investigate(alert: dict, facts: dict) -> str:
    """Alert enrichment — 1-paragraph 'what happened, what is the risk'."""

DatasourceError Storm

Day after deployment: every minute, an URGENT DatasourceError:

[sse.readDataError] [A] got error: input data must be a wide series but got type long

The VictoriaLogs Grafana datasource defaults to queryType: instant (long series). SSEServer-Side ExpressionsGrafana's alerting stage that transforms a query result before the alert condition is evaluated. Grafana 12 requires the three-step query → reduce → threshold form; the older classic-condition shape fails with `sse.parseError`. Not Server-Sent Events, despite the initials. reduce expects wide (Prometheus-style). Fix: queryType: stats in the alert rule model block.

The Digest Was Lying

Two days of digests looked like success, but four things were wrong:

• Request count counted all Hop vhosts, not just blog traffic.
• Top page and top referrer were always blank — no GoatCounter query existed in the digest path.
• Security counted only priority:Critical over the prior calendar day.
• Surge detection filtered _msg:"blog.derio.net" but the vhost lives in request.host, not _msg.

One root cause: the digest read raw Caddy logs as a proxy for “blog activity” without dimensional filters, while GoatCounter sat wired but unqueried. Tests only asserted the parser shape, not the query strings.

Surge That Cried Wolf

Fixing the request.host filter let surge detection fire 370x baseline — on a blog with zero GoatCounter readers. Three compounding bugs: baseline floor of 1 (divide-by-zero guard), 97% of traffic was Frank’s own blackbox probe, and no visitor cross-check was wired.

Agentic Rewrite (June 2026)

The FastAPI analyst was rebuilt as an agentic alert-agent: an autonomous claude session in the multi-agent-shell image, driven over a pod-local HTTP endpoint. The deterministic facts.py/surge.py survived as a frank-facts CLI the agent calls as a shell tool. Seven root causes hid behind “it did not answer” — including tmux-continuum resurrecting dead shells, cold-start missing the first keypress, OOMOut Of MemoryWhat the kernel does when memory runs out — it kills a process by score, not by fault. A container hitting its cgroup limit is killed the same way, which is why the victim is often not the culprit. not graceful-restarting sessions, expired tokens, wrong claude binary in PATH, missing instructions (loaded SKILL.md instead of CLAUDE.md/AGENTS.md), and the answer arriving 5 minutes too slow for the 120s DM timeout.

Six of seven were invisible to ArgoCD. Synced, Healthy, three containers Running — could not answer a single DM.

Missteps

Recovery Path

References

• VictoriaLogs Loki Protocol
• Falco modern_ebpf
• CrowdSec
• GoatCounter

Next: AWX, the Imperative Counterweight
