The First Real Tenant: A vCluster That ArgoCD Deploys Into

In Layer 14 I grew virtual clusters. They booted, they had their own API servers, and I deployed an nginx pod into one to prove the thing worked. Then it sat there, a very elaborate way to run nginx.

A vCluster only earns its keep when something real lives in it, and something real has to arrive the way everything else on me arrives: through Git. That means teaching ArgoCD to treat a virtual cluster as a deployment target — a cluster in its own right, registered alongside the host.

It went badly. Registering the vCluster took down all sixty of my applications at once. Not the tenant. Not the vCluster. Everything.

The fix is six lines of YAML. The order you apply them in is the whole game.

What this gets you, and what you need first

The problem. A vCluster you can’t GitOps into is a pet. You kubectl apply into it by hand, it drifts, and it is not reproducible — which defeats the point of having it.

What’s true after. The vCluster is an ArgoCD cluster target. Applications declare destination.name: <vcluster> and their workloads reconcile inside the virtual cluster, from Git, with self-heal — exactly like host apps.

The load-bearing choice. ArgoCD caches every resource on every cluster it knows about. On a vCluster, caching Pods is what kills it — so the fix is a per-cluster cache exclusion, not a version bump and not an architecture change.

To follow this you need:

• A running vCluster (Layer 14 — the template pattern and the chart schema traps)
• ArgoCD driving your cluster App-of-Apps (Layer 5)
• A way to get secrets into the vCluster (Layer 9 — see “Secrets arrive sideways” below; this bit has its own OSSOpen Source SoftwareSoftware whose source is public and freely modifiable. Worth flagging here because several projects ship an OSS build alongside a paid one, and the difference is often exactly the feature you wanted — LiteLLM's Prometheus metrics are Enterprise-only. trap)

You almost certainly aren’t deploying my tenant. That’s fine — every step below is parameterized, and the failure mode is universal to any vCluster registered against ArgoCD 3.3.x.

Secrets arrive sideways

Before the workloads can start they need their secrets, and inside an OSS vCluster there is no External Secrets Operator and no ClusterSecretStore to resolve them against.

The tempting knob is vCluster’s integrations.externalSecrets. On OSS it is a Pro feature that CrashLoops the control plane on boot — helm template validates it happily, because schema-valid is not the same as edition-available. That cost me a revert.

The OSS-native path: resolve the ExternalSecrets on the host, in the vCluster’s host namespace, then let vCluster sync the resolved Secrets inward.

# apps/vclusters/<vcluster>/values.yaml
sync:
  fromHost:
    secrets:
      enabled: true
      mappings:
        byName:
          # host namespace/secret  ->  in-vCluster namespace/secret
          "<vcluster-ns>/app-secrets": "<tenant-ns>/app-secrets"
          "<vcluster-ns>/ghcr-pull":   "<tenant-ns>/ghcr-pull"

The names and keys stay identical on both sides, so the consuming Deployments never learn which mechanism fed them. Critically, an image-pull secret keeps its kubernetes.io/dockerconfigjson type across the hop — which you only know for certain once a pod actually pulls an image, not from a rendered manifest.

How to register the vCluster without taking the cluster down

Do these in order. Step 2 before step 4 is the entire lesson.

Step 1 — Confirm the panic applies to you

kubectl -n argocd get deploy argocd-server \
  -o jsonpath='{.spec.template.spec.containers[0].image}{"\n"}'

If that reports v3.3.x (or anything vendoring kubectl v0.34.0), you are exposed. Fixed in ArgoCD 3.5; not backported to 3.4.

Step 2 — Add the scoped Pod exclusion, and merge it FIRST

resource.exclusions matches on apiGroups + kinds + clusters — all three must match. The clusters field takes a list of globs, which is what makes this surgical instead of catastrophic.

# apps/argocd/values.yaml -> configs.cm.resource.exclusions
# NOTE: this value REPLACES the chart default (Helm does not merge a multiline
# string), so the chart's own exclusions must be reproduced above this entry.
      - apiGroups:
        - ''
        kinds:
        - Pod
        clusters:
        - https://<vcluster>.<vcluster-ns>.svc:443

Never drop the clusters: scope. A global Pod exclusion also “fixes” the panic — by stripping the pod tree and health rollup from every app on every cluster. It looks like it works. That is what makes it dangerous.

Step 3 — Make the controller actually load it

Resource exclusions are read when a cluster cache is built. Restart the controller now, while the vCluster is still unregistered — there is nothing for it to crash on yet:

kubectl -n argocd delete pod argocd-application-controller-0

Verify the exclusion is live before going further:

kubectl -n argocd get cm argocd-cm \
  -o jsonpath='{.data.resource\.exclusions}' | grep -c '<vcluster-ns>.svc:443'

1 means loaded. 0 means ArgoCD hasn’t synced your change yet — hard-refresh the argocd app and wait. Do not proceed on 0.

Step 4 — Register the vCluster as a cluster target

The client cert and key live in the vCluster’s own vc-<vcluster> secret:

kubectl -n <vcluster-ns> get secret vc-<vcluster> \
  -o jsonpath='{.data.client-certificate}'   # -> certData
kubectl -n <vcluster-ns> get secret vc-<vcluster> \
  -o jsonpath='{.data.client-key}'           # -> keyData

Build an ArgoCD cluster Secret from them:

apiVersion: v1
kind: Secret
metadata:
  name: cluster-<vcluster>
  namespace: argocd
  labels:
    argocd.argoproj.io/secret-type: cluster
type: Opaque
stringData:
  name: <vcluster>
  server: https://<vcluster>.<vcluster-ns>.svc:443
  config: |
    {"tlsClientConfig":{"insecure":true,"certData":"<base64>","keyData":"<base64>"}}

Two traps in that tiny blob:

• insecure: true and caData are mutually exclusive. Ship both and ArgoCD refuses with “specifying a root certificates file with the insecure flag is not allowed.” The vCluster’s serving cert has no SAN for the in-cluster service name, so on an internal cluster insecure: true and no caData is the pragmatic pairing.
• This Secret is applied out-of-band, not through Git — it carries client credentials.

Verify

Watch the controller for ninety seconds. This is the moment the old failure mode would have fired, ~0.3s after the cache sync starts:

kubectl -n argocd get pod argocd-application-controller-0 \
  -o jsonpath='{.status.containerStatuses[0].restartCount}{"\n"}'
kubectl -n argocd logs argocd-application-controller-0 --since=2m | grep -c 'panic:'

Success signature: 0 and 0, held steady, while your tenant apps leave Unknown and start reconciling. Any non-zero restartCount, or any panic: line, means the exclusion did not load — go to Recover, then back to Step 2.

Recover — when the controller is already crashlooping

If you registered first and read this second, the symptom is unmistakable: the application-controller is in CrashLoopBackOff and every application has stopped reconciling. Two commands:

# 1. Remove the trigger.
kubectl -n argocd delete secret cluster-<vcluster>
# 2. Give the controller a clean start.
kubectl -n argocd delete pod argocd-application-controller-0

It comes back healthy and re-reconciles everything. Then do Step 2 → Step 3 → Step 4, in that order.

One thing not to try: clearing a wedged sync operation with kubectl patch application ... -p '{"operation":...}'. The operation is controller-owned; the patch does nothing. Delete the offending resource instead.

Reference

What the exclusion does and doesn’t touch. ArgoCD never manages Pods — they are created by Deployments, StatefulSets and Jobs. The cache is a read-model for the UI tree and health rollup. So excluding Pods changes what ArgoCD displays, not what it does: app health still rolls up from workload status, and a PreSync Job hook still reports from the Job, not its Pod.

Remove it when you reach 3.5. It is a dated workaround, not architecture.

Explanation — why a virtual cluster crashes a real one

Here is the stack, read from the controller’s last words:

panic: assignment to entry in nil map
  k8s.io/kubectl/pkg/util/resource.maxResourceList        resource.go:179
  ...PodRequestsAndLimits                                 resource.go:36
  argo-cd/v3/controller/cache.populatePodInfo             controller/cache/info.go:462
  ...gitops-engine clusterCache.sync -> listResources -> EachListItem

As ArgoCD builds a cluster’s cache it walks every resource and, for Pods, computes their resource requests for display. kubectl v0.34.0’s helper writes into a ResourceList map that it never initialised when the Pod’s requests were defaulted by a LimitRange. Writing to a nil map in Go is a panic.

Now the irony. Layer 14 listed the LimitRange as a feature — “quotas and limit ranges bound what the tenant can consume.” vCluster ships one by default. The isolation primitive I praised is precisely what fed ArgoCD the pod shape that killed it.

Two properties turn a display bug into an outage:

1. The panic is uncaught, in a background goroutine. gitops-engine syncs clusters concurrently via an errgroup. An unrecovered panic there doesn’t fail one cluster’s cache — it takes down the whole process, and with it every other cluster.
2. It is latent. The cache builds incrementally at first and everything looks fine. The full rebuild happens on a cold start — so the bomb is armed by registration and detonated by the next controller restart, which may be hours later and look entirely unrelated.

That second property is why the recovery is “delete the cluster Secret”, not “restart the controller”. Restarting is what triggers it.

Why scoped, not global

The exclusion is evaluated per cluster, so scoping it by clusters: keeps the host cluster’s pod tree intact while the vCluster’s Pods are never listed:

    flowchart LR
  C[application-controller] --> H[host cluster]
  C --> V[vCluster]
  H --> HP["Pods cached<br/>tree + health intact"]
  V --> VP["Pods skipped<br/>populatePodInfo never runs"]


A global exclusion reaches the same “no panic” outcome by blinding you everywhere. Both look green. Only one is correct — which is why the guard test that matters isn’t “is the exclusion present” but “is it ever global”:

# scripts/tests/test_argocd_vcluster_pod_exclusion.py
def test_pod_exclusion_is_never_global():
    for e in _pod_exclusion_entries(_exclusions()):
        assert e.get("clusters"), f"Pod exclusion is GLOBAL (no `clusters` scope): {e}"

Two companions guard the rest: no exclusion glob may match the host cluster URL, and every chart-default exclusion must survive the value override — because setting resource.exclusions replaces the chart’s defaults rather than merging with them, and silently dropping them is a regression nobody would notice.

The thing both traps had in common

The Pro-only integration rendered cleanly. The LimitRange panic rendered cleanly. helm template proved schema in both cases and told me nothing about runtime, which is where both actually failed. A manifest that renders is not a system that runs — the only proof that counts is a pod that pulled its image and a controller that stayed up.

Where it landed

Registered clean: controller restartCount=0, zero panics, through registration and a full cache build. The tenant’s migration hook ran, its services came up, and its images pulled through the sideways-delivered credentials — the first workload on me that arrived in a virtual cluster entirely through Git.

The nginx pod in Layer 14 proved a vCluster could exist. This one proves a vCluster can be part of the cluster — declared, reconciled, and self-healing, same as everything else.

It only cost me every application I run, once, for about eleven minutes.
