Operating on Multi-tenancy

Last updated 2026-07-15 ·a77bf48

This is the operational companion to Multi-tenancy. That post covers the architecture and template pattern. This one is what you type when a virtual cluster’s API server isn’t responding, resources aren’t syncing, or a tenant hit their quota.

Before any commands below, source the environment:

source .env          # sets KUBECONFIG, TALOSCONFIG
source .env_devops   # sets OMNICONFIG + service accounts

What Healthy Looks Like

All vCluster StatefulSets are running, each virtual cluster’s API server is responding, and resources sync correctly between virtual and host clusters. ArgoCD applications for each vCluster show Synced and Healthy.

    graph TB
    subgraph host["Host Cluster"]
        subgraph vcNS["vcluster-experiments namespace"]
            vc0["vCluster StatefulSet"]
            syncer["Syncer Container"]
            vc0 -.- syncer
        end
        vc0 --> vAPI["Virtual API Server"]
    end

    subgraph virt["Virtual Cluster"]
        vAPI --> vPod["User Pod"]
        vAPI --> vSvc["User Service"]
    end

    syncer -.->|resource sync| vAPI

Verify

List Virtual Clusters

# Using vcluster CLI
vcluster list

# Check vCluster pods on the host
kubectl get pods -A -l app=vcluster

# Check ArgoCD status for vCluster apps
argocd app list --port-forward --port-forward-namespace argocd | grep vcluster

$ vcluster list

     NAME     |      NAMESPACE       | STATUS  | VERSION | CONNECTED | AGE
  ------------+----------------------+---------+---------+-----------+------
    experiments | vcluster-experiments | Running | 0.32.1  |           | 39d

$ kubectl get statefulset -A -l app=vcluster
NAMESPACE              NAME          READY   AGE
vcluster-experiments   experiments   1/1     39d

Connect to a Virtual Cluster

# Connect and switch kubectl context
vcluster connect <name> --namespace <namespace>

# Verify you are in the virtual cluster
kubectl get nodes
kubectl get namespaces

# Disconnect when done
vcluster disconnect

Check Synced Resources

# From the host cluster, check what the syncer is doing
kubectl logs -n <vcluster-namespace> <vcluster-pod> -c syncer --tail=50

# Check resource sync status
kubectl get pods -n <vcluster-namespace> -l vcluster.loft.sh/managed-by

Steps

Create a New Virtual Cluster

New vClusters follow the template pattern:

cp -r apps/vclusters/template/ apps/vclusters/<new-name>/

Customize apps/vclusters/<new-name>/values.yaml — set the name, resource quotas, and any specific configuration.
Add the ArgoCD Application Custom ResourceAn object of a type Kubernetes did not ship with, added by a CRD. Frank's ArgoCD Applications, Rollouts and Tekton Pipelines are all CRs. in apps/root/templates/vcluster-<new-name>.yaml following the existing pattern.
Commit and push — ArgoCD picks it up automatically.

Delete a Virtual Cluster

Since prune: false, removing a vCluster requires manual cleanup:

# Delete the ArgoCD application
argocd app delete vcluster-<name> --port-forward --port-forward-namespace argocd

# Verify the namespace is cleaned up
kubectl get ns <vcluster-namespace>

Then remove the files from apps/vclusters/<name>/ and apps/root/templates/vcluster-<name>.yaml.

Manage Resource Quotas

# Check current quotas from inside the virtual cluster
vcluster connect <name> --namespace <namespace>
kubectl get resourcequota -A

# Check host-level resource usage for the vCluster namespace
vcluster disconnect
kubectl top pods -n <vcluster-namespace>

To adjust quotas, update the values in apps/vclusters/<name>/values.yaml and let ArgoCD sync.

Recover

Virtual API Server Not Responding

# Check the StatefulSet
kubectl get statefulset -n <vcluster-namespace>
kubectl describe statefulset -n <vcluster-namespace> <vcluster-name>

# Check the PVC for the virtual etcd
kubectl get pvc -n <vcluster-namespace>

# Check pod logs
kubectl logs -n <vcluster-namespace> <vcluster-pod> -c vcluster --tail=100

Common causes: PersistentVolumeClaimA Kubernetes request for durable storage. The pod names a claim and the storage layer — Longhorn on Frank — binds real disk behind it, so the data outlives the pod. stuck pending (storage class issue), resource limits too low for the API server, or the host node where the StatefulSet is scheduled is under pressure.

Resources Not Syncing

# Check syncer logs for errors
kubectl logs -n <vcluster-namespace> <vcluster-pod> -c syncer --tail=100 | grep -i error

# Verify sync configuration in values.yaml
kubectl get configmap -n <vcluster-namespace> -l app=vcluster -o yaml | grep -A 20 sync

Resource Quota Exceeded

# Connect to the virtual cluster and check
vcluster connect <name> --namespace <namespace>
kubectl describe resourcequota -A

# Check which pods are consuming the most
kubectl top pods -A --sort-by=memory
vcluster disconnect

Network Connectivity Issues

# Test DNS from inside the virtual cluster
vcluster connect <name> --namespace <namespace>
kubectl run test --image=busybox --rm -it --restart=Never -- nslookup kubernetes.default

# Test connectivity to a host service
kubectl run test --image=busybox --rm -it --restart=Never -- wget -qO- http://<host-service>
vcluster disconnect

Missteps

What we assumed	Why it was wrong	What it cost
The template pattern means creating a new vCluster is a simple copy-and-commit	Each vCluster needs unique resource quotas, sync config, and ArgoCD Application CR. Forgetting any of the three registration points leaves the vCluster orphaned or misconfigured.	Repeated manual fixes until a checklist was formalized.
`prune: false` means we can delete vCluster manifests without side effects	ArgoCD won’t clean up the namespace or resources when the Application is removed — they must be cleaned manually or they accumulate.	Stale namespaces and PVCs left behind after vCluster deletion.

Quick Reference

Command	What It Does
`vcluster list`	List all virtual clusters
`vcluster connect <name> -n <ns>`	Switch kubectl to virtual cluster
`vcluster disconnect`	Return to host cluster context
`kubectl get pods -A -l app=vcluster`	Check vCluster pods on host
`kubectl logs -n <ns> <pod> -c syncer`	Check resource sync logs
`kubectl logs -n <ns> <pod> -c vcluster`	Check virtual API server logs
`kubectl get pvc -n <ns>`	Check virtual etcd storage
`argocd app list \| grep vcluster`	ArgoCD status for vClusters
