Operating on Hop — Single-Node Talos Edge Cluster

Last updated 2026-07-30

This is the operational companion to Hopping Through the Portal. That post covers the ten deviations from standard Talos. This one covers what you type to keep Hop running.

Hop is a single-node Talos cluster on a CX23 Hetzner VM. Everything about it differs from Frank.

Hop has no redundancy. A node reboot means all services are down. A botched Talos upgrade means rebuilding from Packer snapshot. Treat Hop as a pet.

    graph TB
    subgraph internet["Internet"]
        user["User"]
        attacker["Scanner / Attacker"]
    end

    subgraph hetzner["Hetzner Cloud"]
        direction TB
        hop["hop-1<br/>CX23 VM<br/>Talos Linux"]

        subgraph k8s["Kubernetes"]
            direction TB
            caddy["Caddy<br/>hostPort 80/443"]
            cs["CrowdSec<br/>LAPI + Bouncer"]
            hs["Headscale<br/>Control Server"]
            hp["Headplane<br/>Admin UI"]
            blog["Blog<br/>Hugo static"]
        end

        vol["Hetzner Volume<br/>10GB<br/>headscale db + caddy certs"]
        caddy -.->|logs →| cs
        cs -->|ban decision| caddy
        hs --- vol
    end

    subgraph mesh["Tailscale Mesh"]
        direction TB
        laptop["Laptop"]
        raspi["Raspi<br/>Subnet Router"]
        phone["Phone"]
    end

    user -->|https://blog.derio.net| caddy
    attacker -->|scan| caddy
    cs -->|block| attacker
    hs --- laptop
    hs --- raspi
    hs --- phone


Before any commands, source the Hop environment:

source .env_hop

# Verify you're targeting the right cluster
kubectl get nodes
# Expected: hop-1   Ready   control-plane   ...

Never run source .env in a Hop terminal — it overwrites KUBECONFIG with Frank’s config. If unsure: kubectl config current-context should show admin@hop.

What Healthy Looks Like

• talosctl health passes on the public IP.
• All system pods are Running or Completed — no Pending or CrashLoopBackOff.
• Caddy responds on both public and mesh entrypoints.
• Headscale shows all registered nodes as online.
• CrowdSec ban pipeline is active (no “0 bans” forever).
• The Hetzner Volume is attached to hop-1.

Verify

# Cluster
talosctl -n $HOP_IP health
kubectl get nodes -o wide
kubectl get pods -A | grep -v Running | grep -v Completed

# Caddy
curl -sI https://blog.derio.net/frank/ | head -3
kubectl -n caddy-system logs deploy/caddy --tail=5 | grep "tls\|cert"

# Headscale
kubectl -n headscale-system exec deploy/headscale -- headscale nodes list
kubectl -n headscale-system exec deploy/headscale -- headscale routes list

# CrowdSec
kubectl -n crowdsec-system exec deploy/crowdsec-lapi -- cscli metrics | head -15

# Storage
hcloud volume list
kubectl get pv | grep -v Bound

Steps

Add a Node to the Mesh

# 1. Create a pre-auth key (on workstation with .env_hop sourced)
kubectl -n headscale-system exec deploy/headscale -- \
  headscale preauthkeys create --user default --reusable --expiration 24h

# 2. On the new device:
sudo tailscale up \
  --login-server https://headscale.hop.derio.net \
  --accept-routes \
  --authkey <KEY>

# 3. Verify
kubectl -n headscale-system exec deploy/headscale -- headscale nodes list | grep online

Reload Caddy Config

kubectl -n caddy-system rollout restart deploy/caddy

Caddy uses Recreate strategy (binds host port 80/443 — rolling update would deadlock). Expect ~5s downtime.

Upgrade Talos

Service-impacting — all pods stop during reboot.

# Check current version
talosctl -n $HOP_IP version

# Stage
talosctl -n $HOP_IP upgrade --image ghcr.io/siderolabs/installer:<VERSION> --stage

# Reboot
talosctl -n $HOP_IP reboot

# Wait for recovery
talosctl -n $HOP_IP health
kubectl get pods -A

Expected downtime: 3–5 minutes.

Backup Headscale DB

kubectl -n headscale-system exec deploy/headscale -- \
  sqlite3 /var/lib/headscale/db.sqlite \
  ".backup /var/lib/headscale/backups/manual-$(date +%F).db"

An automated CronJob runs daily at 3 AM UTC. Retention is 7 days on the Hetzner Volume.

Recover

Caddy TLS Expired

# Check token is valid (shows last 4 chars)
kubectl -n caddy-system get secret caddy-cloudflare -o jsonpath='{.data.api-token}' | base64 -d | tail -c 4

# Recreate if empty, then restart pod
kubectl -n caddy-system delete secret caddy-cloudflare
kubectl -n caddy-system create secret generic caddy-cloudflare \
  --from-literal=api-token=<TOKEN>
kubectl -n caddy-system rollout restart deploy/caddy

Gotcha: Env vars from secretKeyRef are injected at pod creation. A pod keeps running with a valid token long after the secret is deleted. You find out on the next restart.

CrowdSec Stops Banning

# Check LAPI health
kubectl -n crowdsec-system logs deploy/crowdsec-lapi --tail=20

# Check bouncer is connected
kubectl -n crowdsec-system exec deploy/crowdsec-lapi -- cscli bouncers list

# Check metric collection
kubectl -n crowdsec-system exec deploy/crowdsec-lapi -- cscli metrics

The ban pipeline can fail silently. A CrowdSec canary exists that pages when no new bans appear over a threshold — but the canary itself depends on the pipeline being wired correctly. Known failure modes:

• Caddy logs not ingested — CrowdSec needs container_runtime=containerd in its Caddy parser config to parse Caddy’s JSON logs correctly (#584).
• LAPILocal APICrowdSec's local decision service. Agents report parsed events to it and bouncers ask it who to block — which means if its database is ephemeral, the whole ban pipeline silently does nothing. data not persisted — If the LAPI pod restarts without a PVCPersistentVolumeClaimA Kubernetes request for durable storage. The pod names a claim and the storage layer — Longhorn on Frank — binds real disk behind it, so the data outlives the pod., it forgets all decisions. The fix was adding a PVC for /var/lib/crowdsec/data (#583).
• Bouncer can’t reach LAPI — The Caddy CrowdSec bouncer was initially pointed at the wrong service name. Fixed in #574.
• Log rotation kills ingestion — Caddy’s log rotation closes the file descriptor. CrowdSec needs poll_without_inotify: true to detect the new log file (#594).

Mesh Client Can’t Route

# From the client
tailscale status
tailscale ip -4          # Should show 100.64.0.x
dig litellm.frank.derio.net  # Should resolve via split DNS

Common fixes:

• --accept-routes missing: run sudo tailscale set --accept-routes
• net.ipv4.ip_forward=1 missing for exit node: add it and restart tailscale
• Split DNS not working: check Headscale ConfigMap dns.nameservers.split section

Headscale Pod Won’t Start

kubectl -n headscale-system logs deploy/headscale --tail=30

Known causes:

• SQLite DB corruption from unclean shutdown — restore from backup.
• Falco alert killing the backup CronJob pod (bake sqlite binary into the image to avoid the exec probe) — fixed in #385.

Complete Cluster Rebuild

# 1. Create new server from Talos snapshot
hcloud server create --name hop-1 --type cx23 --location fsn1 \
  --image <SNAPSHOT_ID> --volume hop-data

# 2. Apply Talos config
talosctl apply-config --insecure -n <NEW_IP> --file controlplane.yaml
talosctl bootstrap -n <NEW_IP>

# 3. Wait, bootstrap ArgoCD, re-create secrets
talosctl -n <NEW_IP> health
helm install argocd argo/argo-cd -n argocd --create-namespace \
  -f clusters/hop/apps/argocd/values.yaml
kubectl apply -f <(helm template root clusters/hop/apps/root/)

# 4. Manually re-create cloudflare and tailscale secrets

The Hetzner Volume survives server deletion. Reattach to the new server and Headscale clients reconnect automatically.

Headscale API-Key Expiry

Headscale API keys fail silently at expiry: Headplane remains Running, ArgoCD remains green, and login stops working. The headscale-api-key-expiry CronJob checks both consumer keys hourly and warns 30 days before the earliest expiry.

# Inspect the schedule and recent results.
kubectl -n headscale-system get cronjob headscale-api-key-expiry
kubectl -n headscale-system get jobs -l app.kubernetes.io/name=headscale-api-key-expiry

# Run it immediately after rotating either API key.
kubectl -n headscale-system delete job headscale-api-key-expiry-manual --ignore-not-found
kubectl -n headscale-system create job \
  --from=cronjob/headscale-api-key-expiry headscale-api-key-expiry-manual
kubectl -n headscale-system logs -f job/headscale-api-key-expiry-manual

A healthy line contains verdict=ok alert=false checked=2. verdict=warn means the earliest expected key has 30 days or less remaining. verdict=error means an expected prefix disappeared or the API could not be authenticated/read. The Frank Grafana rules headscale-api-key-expiry-warning and headscale-api-key-expiry-heartbeat-stale page Telegram directly.

When rotating, update EXPECTED_PREFIXES in clusters/hop/apps/headscale/manifests/key-expiry-cronjob.yaml with both new seven-character prefixes before deleting the old keys. The monitor intentionally tracks Headplane’s key and the operator API key separately.

Missteps

Quick Reference

Operating www.derio.net

The second public site on the edge. Source lives in a private repo; only the deployment manifest and the vhost live here.

Is it serving the real page or the fallback?

The vhost falls back to a holding page when its backend is unreachable, so a 200 alone does not mean the site is healthy. Check for content:

curl -sI https://www.derio.net | head -1          # 200 either way
curl -s  https://www.derio.net | grep -q counter.derio.net \
  && echo "serving the built page" || echo "serving the fallback"

If it is on the fallback, the backend is the place to look:

source .env_hop
kubectl -n www-system get pods
kubectl -n www-system describe pod -l app.kubernetes.io/name=www | tail -20

An ImagePullBackOff on a 40-zero tag means no promotion has ever run — the placeholder is still in place.

A change was merged but the site is unchanged

The chain has four hops, and each one fails quietly:

# 1. Did the mirror receive it?
kubectl -n tekton-pipelines logs -l eventlistener=github-listener --tail=20

# 2. Did Gitea Actions build it? (Gitea UI -> agentic-stoa/site -> Actions)
#    No Actions tab at all means the repo's Actions unit was never enabled.

# 3. Did promotion run?
kubectl -n tekton-pipelines get pipelinerun \
  -l tekton.dev/pipeline=site-promotion --sort-by=.metadata.creationTimestamp | tail -5

# 4. Did ArgoCD roll it?
kubectl -n argocd get application www -o wide      # on Hop

A promotion run that fails on git push almost always means the derio-net installation token is not materialising — see frank-gitops-push in the storage/secrets runbook. That same credential backs CNC promotion, so if it is broken here it is broken there too.

Response headers

Both public sites import a shared Caddy snippet. To verify after a Caddy change:

curl -sI https://www.derio.net  | grep -iE "strict-transport|content-security|x-content-type"
curl -sI https://blog.derio.net | grep -iE "strict-transport|content-security|x-content-type"

The CSPContent Security PolicyA response header telling the browser which sources of script, style and images to trust. Frank's blog serves `script-src 'self'`, which is why inline scripts had to be replaced rather than tolerated. permits exactly one external origin (analytics). If a page starts loading anything else — a font, a script, an embed — the browser blocks it silently while the page still returns 200. Check the browser console, not the server, when analytics or an embed “just stops working”.

References

• Building Post — Hopping Through the Portal
• Headscale CLI Reference
• Talos Linux Operations
• Caddy Documentation
