Operating on Health Bridge
Operating on Health Bridge

Operating on Health Bridge

Companion to Health Bridge — Closing the Loop from Grafana Alerts to GitHub Issues.

Quick Reference

ComponentNamespacePortPurpose
health-bridgemonitoring8080Grafana webhook → GitHub lifecycle updates
Webhook endpoint——POST /webhook (Bearer auth)
Health check——GET /healthz
Readiness check——GET /readyz

Checking Service Status

# Pod status
kubectl get pods -n monitoring -l app=health-bridge

# Recent logs
kubectl logs -n monitoring -l app=health-bridge --tail=20

# Check readiness (should show project metadata loaded)
kubectl logs -n monitoring -l app=health-bridge | grep "Loaded project metadata"
# Expected: Loaded project metadata: id=..., field=..., 10 lifecycle states

Testing the Webhook

# Get webhook secret
WEBHOOK_SECRET=$(kubectl get secret -n monitoring health-bridge-secrets \
  -o jsonpath='{.data.WEBHOOK_SECRET}' | base64 -d)

# Send a test alert (warning → degraded)
curl -s -X POST http://health-bridge.monitoring.svc.cluster.local:8080/webhook \
  -H "Authorization: Bearer $WEBHOOK_SECRET" \
  -H "Content-Type: application/json" \
  -d '{
    "status": "firing",
    "alerts": [{
      "status": "firing",
      "labels": {"alertname": "test-bridge", "severity": "warning", "github_issue": "willikins#11"},
      "annotations": {"summary": "Manual test alert"},
      "startsAt": "'$(date -u +%Y-%m-%dT%H:%M:%SZ)'"
    }]
  }'
# Expected: {"processed": 1, "total": 1}

# Send a resolved alert to restore healthy state
curl -s -X POST http://health-bridge.monitoring.svc.cluster.local:8080/webhook \
  -H "Authorization: Bearer $WEBHOOK_SECRET" \
  -H "Content-Type: application/json" \
  -d '{
    "status": "resolved",
    "alerts": [{
      "status": "resolved",
      "labels": {"alertname": "test-bridge", "severity": "warning", "github_issue": "willikins#11"},
      "annotations": {"summary": "Manual test resolved"},
      "startsAt": "'$(date -u +%Y-%m-%dT%H:%M:%SZ)'",
      "endsAt": "'$(date -u +%Y-%m-%dT%H:%M:%SZ)'"
    }]
  }'
# Expected: {"processed": 1, "total": 1}

Checking ExternalSecret Sync

# Verify secrets are synced from Infisical
kubectl get externalsecret -n monitoring health-bridge-secrets
# Expected: STATUS=SecretSynced

# Check secret keys exist (don't print values)
kubectl get secret -n monitoring health-bridge-secrets -o jsonpath='{.data}' | jq 'keys'
# Expected: ["GITHUB_TOKEN", "WEBHOOK_SECRET"]

Managing Alert Rule Labels

Alert rules need a github_issue label for the bridge to process them. Current mappings:

Alert Rule UIDgithub_issue
exercise-reminder-stalewillikins#11
session-manager-stalewillikins#13
audit-digest-stalewillikins#12
agent-pod-not-runningfrank#8
endpoint-down(none — future work)
GRAFANA_AUTH="admin:$(kubectl get secret -n monitoring victoria-metrics-grafana \
  -o jsonpath='{.data.admin-password}' | base64 -d)"

# List all rules with their github_issue labels
curl -s -u "$GRAFANA_AUTH" \
  "https://grafana.frank.derio.net/api/v1/provisioning/alert-rules" | \
  jq '.[] | {title: .title, uid: .uid, github_issue: .labels.github_issue}'

# Add or update a github_issue label on a rule
RULE_UID="exercise-reminder-stale"
ISSUE="willikins#11"
RULE=$(curl -s -u "$GRAFANA_AUTH" \
  "https://grafana.frank.derio.net/api/v1/provisioning/alert-rules/$RULE_UID")
UPDATED=$(echo "$RULE" | jq --arg issue "$ISSUE" '.labels.github_issue = $issue')
curl -s -X PUT "https://grafana.frank.derio.net/api/v1/provisioning/alert-rules/$RULE_UID" \
  -u "$GRAFANA_AUTH" \
  -H "Content-Type: application/json" \
  -d "$UPDATED"

Managing the Grafana Contact Point

GRAFANA_AUTH="admin:$(kubectl get secret -n monitoring victoria-metrics-grafana \
  -o jsonpath='{.data.admin-password}' | base64 -d)"

# List contact points
curl -s -u "$GRAFANA_AUTH" \
  "https://grafana.frank.derio.net/api/v1/provisioning/contact-points" | \
  jq '.[] | {uid: .uid, name: .name, type: .type}'

# Check notification policy routing
curl -s -u "$GRAFANA_AUTH" \
  "https://grafana.frank.derio.net/api/v1/provisioning/policies" | jq .

Verifying GitHub Integration

# Check a specific issue's lifecycle state on the project board
gh issue view 11 --repo derio-net/willikins --json projectItems \
  --jq '.projectItems[]'

# Check recent comments added by the bridge
gh issue view 11 --repo derio-net/willikins --json comments \
  --jq '.comments[] | select(.body | contains("health-bridge")) | {createdAt, body}'

Auto-Close of Healed Bug Issues (v0.3.0)

Since v0.3.0, the loop closes itself. When an alert resolves, the bridge finds every open [Bug] <alertname> is dead — … issue it created for that alert and closes it (state_reason: completed) with a heal comment carrying the resolution time and outage duration. A transient incident is now fully self-cleaning: dead → bug filed → healed → bug closed, no operator touch.

Matching is deliberately strict — both conditions must hold:

  1. Title prefix: [Bug] <alertname> is dead
  2. Body contains the newline-terminated feature ref the bug was created with: **Feature Issue:** derio-net/<repo>#<N>

The second condition exists because Grafana’s synthetic DatasourceError alertname is shared across layers — title-only matching would let an L24 resolve close an L8 bug. The newline termination stops #2 from matching #24.

Operational notes:

  • The close path keys purely on status: resolved — it is not gated by the per-tracker dedup (a repeated resolved notification is an idempotent no-op) and not gated by severity (editing a rule’s severity label between fire and resolve won’t strand a bug).
  • All matching open bugs close at once, which also sweeps historical duplicates from the pre-dedup era.
  • A resolved webhook missed while the bridge pod is down means that bug stays open — close it by hand. There is deliberately no Grafana-state reconciler (resolved delivery has been reliable in practice); if stale bugs recur, that’s the documented follow-up.
# Verify recent auto-closes
kubectl logs -n monitoring -l app=health-bridge --tail=50 | grep "Closed bug issue"
gh issue list -R derio-net/frank-ops --label bug --state closed --limit 5

Troubleshooting

Bridge not processing alerts

  1. Check pod logs for errors:

    kubectl logs -n monitoring -l app=health-bridge --tail=50

  2. Verify the webhook contact point exists in Grafana:

    curl -s -u "$GRAFANA_AUTH" \
  "https://grafana.frank.derio.net/api/v1/provisioning/contact-points" | \
  jq '.[] | select(.name == "Health Bridge Webhook")'

  3. Verify the notification policy routes Feature Health alerts:

    curl -s -u "$GRAFANA_AUTH" \
  "https://grafana.frank.derio.net/api/v1/provisioning/policies" | \
  jq '.routes[] | select(.receiver == "Health Bridge Webhook")'

“not ready” on readiness probe

The bridge couldn’t load project metadata from GitHub on startup. Check:

# Pod logs will show the error
kubectl logs -n monitoring -l app=health-bridge | head -5

# Common causes:
# - GITHUB_TOKEN expired or missing scopes (needs repo, project, read:org)
# - Project number wrong (check PROJECT_NUMBER in configmap)
# - GitHub API rate limit hit

Alerts skip the bridge (no github_issue label)

Bridge logs show Alert <name> has no github_issue label, skipping. Add the label to the alert rule — see “Managing Alert Rule Labels” above.

Duplicate bug issues appearing

Symptom: Multiple identical [Bug] ... is dead issues created for the same alert.

Cause: Before v0.2.0, the bridge had no dedup logic. If you’re running v0.1.0 or earlier, upgrade.

If running v0.2.0+: This can happen once after a pod restart (in-memory state is lost). The GitHub search safety net should prevent all but the first duplicate. If duplicates persist, check pod restart frequency.

v0.3.0 changes the search semantics: the safety net (FindOpenBugs, replacing HasOpenBug) matches the title prefix and the **Feature Issue:** body ref. Two consequences: layers sharing an alertname (DatasourceError) no longer suppress each other’s legitimate bugs, and any duplicates that do slip through are all closed together the next time the alert resolves.

Cleanup: usually unnecessary on v0.3.0+ — wait for the resolve. To close by hand: gh issue close <number> --repo derio-net/<repo> --comment "Duplicate", keeping the earliest one open.

A Layer flaps to degraded after a Job or one-off pod runs

Symptom: A Layer tile goes degraded (and an L<N> ... failing alert fires) with no real outage. The named component is a pod that has already Completed — typically a Job pod or a one-off kubectl-applied debug pod.

Cause: A pod reports kube_pod_status_ready{condition="true"}=0 the instant it terminates. Rules that select a whole namespace — the Layer 8 Observability rule sweeps all of monitoring — pick those corpses up as if they were unready workloads.

Fix: The Layer 8 rule already excludes terminated pods with unless on(namespace,pod) kube_pod_status_phase{phase=~"Succeeded|Failed"} == 1. If a new namespace-wide rule shows the same flap, add the same guard. To find the culprit and clear a stray corpse:

# Which monitoring pods currently report ready=0?
kubectl exec -n monitoring deploy/blackbox-exporter -- wget -qO- \
  'http://vmsingle-victoria-metrics-victoria-metrics-k8s-stack:8428/api/v1/query?query=kube_pod_status_ready{namespace="monitoring",condition="true"}==0'

# Leftover Completed pods in the namespace?
kubectl get pods -n monitoring --field-selector=status.phase=Succeeded
# Delete a confirmed corpse:
kubectl delete pod <name> -n monitoring

GitHub API errors

# Check for GitHub API errors in logs
kubectl logs -n monitoring -l app=health-bridge | grep -i error

# Verify GitHub token scopes (from outside the cluster)
curl -sI -H "Authorization: Bearer $(kubectl get secret -n monitoring health-bridge-secrets \
  -o jsonpath='{.data.GITHUB_TOKEN}' | base64 -d)" \
  https://api.github.com/ | grep -i x-oauth-scopes

Updating the Bridge

# In the health-bridge repo:
# 1. Make changes, run tests
go test -v ./...

# 2. Tag and push
git tag v0.2.0
git push origin v0.2.0
# GitHub Actions builds and pushes to GHCR

# 3. Update the image tag in frank repo
# Edit apps/health-bridge/manifests/deployment.yaml
# Change: image: ghcr.io/derio-net/health-bridge:v0.2.0
# Commit and push — ArgoCD syncs automatically

Layer trackers (Pass 3)

As of 2026-04-20, the 20 Layer tracker Issues on the Derio Ops board were relocated from the public derio-net/frank to the private derio-net/frank-ops repo, with Issue numbers aligned 1:1 to Layer numbers (so frank-ops#13 is Layer 13 Authentik). Each Layer has one Grafana alert rule with github_issue: "frank-ops#<LAYER>" driving its Lifecycle field automatically.

Smoke-testing a Layer via direct webhook

The direct-Bridge test bypasses Grafana’s rule evaluation, which is handy for verifying the Bridge + GitHub path without waiting for a real metric to dip:

export WEBHOOK_SECRET=$(kubectl get secret -n monitoring health-bridge-secrets \
  -o jsonpath='{.data.WEBHOOK_SECRET}' | base64 -d)
kubectl port-forward -n monitoring svc/health-bridge 8080:8080 &

# Fire a critical alert at Layer 13 (Authentik)
curl -s -X POST http://localhost:8080/webhook \
  -H "Authorization: Bearer $WEBHOOK_SECRET" -H "Content-Type: application/json" \
  -d '{"status":"firing","alerts":[{
    "status":"firing",
    "labels":{"alertname":"smoke","severity":"critical","github_issue":"frank-ops#13"},
    "annotations":{"summary":"Smoke test"},
    "startsAt":"2026-04-20T00:00:00Z"
  }]}'
# Response: {"processed": 1, "total": 1}

Checking a Layer’s current Lifecycle state

gh api graphql -f query='
{
  repository(owner:"derio-net", name:"frank-ops") {
    issue(number:13) {
      projectItems(first:5) {
        nodes {
          fieldValueByName(name:"Lifecycle") {
            ... on ProjectV2ItemFieldSingleSelectValue { name }
          }
        }
      }
    }
  }
}' --jq '.data.repository.issue.projectItems.nodes[].fieldValueByName.name'
# → healthy  (or degraded, dead, etc.)

Reloading rules after editing the ConfigMap

Grafana’s provisioning files are read at boot, not watched. After editing apps/grafana-alerting/manifests/alert-rules-cm.yaml:

git add apps/grafana-alerting/manifests/alert-rules-cm.yaml
git commit -m "feat(obs): ..."
git push origin main

# Wait for ArgoCD to sync the ConfigMap
kubectl annotate application -n argocd grafana-alerting \
  argocd.argoproj.io/refresh=hard --overwrite

# Restart Grafana to pick up the new ConfigMap
kubectl delete pod -n monitoring -l app.kubernetes.io/name=grafana

Two gotchas learned the hard way:

  1. RWO PVC + RollingUpdate deadlock. Grafana’s PVC is ReadWriteOnce. When the Deployment rolls due to a ConfigMap checksum change, the new pod can’t mount the volume while the old pod holds it. If the rollout hangs, scale the Deployment to 0 briefly to force a detach, then back up. A more durable fix (switch strategy.type to Recreate) is tracked as a follow-up.
  2. Listen for parseError in the new pod’s logs before trusting that a rule change took effect:
    kubectl logs -n monitoring -l app.kubernetes.io/name=grafana --tail=200 | grep -iE 'parseError|provisioning.*error'

Verifying a rule is loaded via the Grafana API

GRAFANA_POD=$(kubectl get pods -n monitoring -l app.kubernetes.io/name=grafana \
  -o jsonpath='{.items[0].metadata.name}')
ADMIN_PASS=$(kubectl get secret -n monitoring victoria-metrics-grafana \
  -o jsonpath='{.data.admin-password}' | base64 -d)

kubectl exec -n monitoring "$GRAFANA_POD" -c grafana -- \
  curl -s -u admin:"$ADMIN_PASS" \
  http://localhost:3000/api/v1/provisioning/alert-rules/layer-13-auth-down \
  | jq '{uid, title, labels, annotations}'

Recovering stranded board tiles / bugs after an outage

Since v0.4.0 the Bridge maps DatasourceError/NoData to degraded with no bug (a blind sensor isn’t a corpse), and the heal path closes bugs by feature-ref regardless of alertname — so a recovery resolve closes a bug even when its firing alertname differed. That removes the usual stranding.

It can still happen, though, when Grafana is replaced by a fresh pod mid-incident (a power outage is the classic case): the new process never fired the alert, so it never sends the resolved. The tile stays dead/degraded and any bug stays open, because the Bridge only ever knows what a webhook tells it. The cure is to tell it — replay the missing resolved against the Bridge’s own idempotent path. It will flip the tiles to healthy and close the matching bugs with proper heal comments.

First confirm the underlying services are actually healthy (don’t paper over a real outage), then:

cd <frank-repo> && source .env   # KUBECONFIG is a relative path — cd first

# Webhook secret, read live (never inline it):
SECRET=$(kubectl get secret -n monitoring health-bridge-secrets \
  -o jsonpath='{.data.WEBHOOK_SECRET}' | openssl base64 -d -A)

# The frank-ops# trackers that are stuck (from the bridge logs / board):
ISSUES="18 1 12 13 15 24 3 5 6 8"
NOW=$(date -u +%Y-%m-%dT%H:%M:%SZ)
alerts=""
for n in $ISSUES; do
  alerts="${alerts}{\"status\":\"resolved\",\"labels\":{\"alertname\":\"DatasourceError\",\"github_issue\":\"frank-ops#${n}\",\"severity\":\"critical\"},\"annotations\":{\"summary\":\"Outage recovery\"},\"startsAt\":\"${NOW}\",\"endsAt\":\"${NOW}\"},"
done
payload="{\"status\":\"resolved\",\"alerts\":[${alerts%,}]}"

kubectl port-forward -n monitoring svc/health-bridge 18080:8080 >/tmp/hb-pf.log 2>&1 &
PF=$!; trap 'kill $PF 2>/dev/null' EXIT; sleep 3
curl -sS -X POST http://127.0.0.1:18080/webhook \
  -H "Authorization: Bearer ${SECRET}" -H "Content-Type: application/json" \
  -d "${payload}"

alertname: DatasourceError is the key: it makes the bridge match the [Bug] DatasourceError is dead titles for the create-era bugs, while the feature-ref close (v0.4.0) handles anything titled differently. The whole thing is idempotent — re-running on already-healthy tiles with no open bugs is a no-op. Verify with kubectl logs -n monitoring -l app=health-bridge --tail=40 | grep -E 'Closed bug|→ healthy'.

Operating on Health MonitoringOperating on In-Cluster Ingress
