Operating on VK Relay

Last updated 2026-07-15 ·eff627f

This is the operational companion to VK Relay. That post explains the architecture and deployment. This one is the day-to-day runbook.

    sequenceDiagram
    participant Browser as Remote Browser<br/>vk.cluster.derio.net
    participant Traefik as Traefik<br/>(ingress)
    participant Relay as Relay Server<br/>(vk-remote:8082)
    participant Local as Local VK Server<br/>(secure-agent-pod:8081)
    participant Agent as Agent Workspace

    Browser->>Traefik: WebSocket connect /v1/relay/connect
    Traefik->>Relay: route to relay-server
    Relay->>Local: tunnel WebSocket
    Note over Relay,Local: pairing code handshake
    Local->>Agent: query workspace data
    Agent-->>Local: repos, sessions, diffs
    Local-->>Relay: relay response
    Relay-->>Browser: render workspace UI

What Healthy Looks Like

The vk-remote pod has two containers: vk-remote and relay-server, both Running.
Relay server is listening on port 8082.
GET https://vk.cluster.derio.net/v1/relay/connect returns 401 (JSON Web TokenA signed, self-describing token carrying claims — who you are, what you may do, when it expires. Readable by anyone holding it, so the expiry and signature are the only things protecting it. auth required — means the relay is up and routing).
A browser is paired and shows workspace data through the remote UI.

Verify

# Pod health
kubectl -n agents get pods -l app=vk-remote -o wide

# Relay logs
kubectl -n agents logs deploy/vk-remote -c relay-server --tail=10

# Endpoint reachable (expect 401)
curl -s -o /dev/null -w "%{http_code}" https://vk.cluster.derio.net/v1/relay/connect

# Local server relay connection
kubectl -n secure-agent-pod exec deploy/secure-agent-pod -c kali -- \
  env | grep VK_SHARED_RELAY
# Expected: VK_SHARED_RELAY_API_BASE=https://vk.cluster.derio.net

$ kubectl -n agents get pods -l app=vk-remote
NAME                         READY   STATUS    RESTARTS   AGE
vk-remote-7949d8bb66-vpgpx   2/2     Running   0          21h

$ curl -s -o /dev/null -w "%{http_code}" https://vk.cluster.derio.net/v1/relay/connect
401

Steps

Restart the Relay

kubectl -n agents rollout restart deploy/vk-remote
kubectl -n agents rollout status deploy/vk-remote

Re-Pair a Browser

# 1. Port-forward to the local VK server
kubectl -n secure-agent-pod port-forward deploy/secure-agent-pod 8081:8081

# 2. Open http://localhost:8081 → Settings → Relay Settings → "Generate pairing code"

# 3. Open https://vk.cluster.derio.net → Settings → "Pair host" → enter code

# 4. Stop the port-forward

Recover

502 on Relay Endpoint

# Check relay container
kubectl -n agents describe pod -l app=vk-remote | grep -A5 relay-server
kubectl -n agents logs deploy/vk-remote -c relay-server --previous

The relay-server container is likely crashing. Check for port conflicts or startup failures.

Workspace Data Not Loading

Symptom: the remote UI shows workspaces but they’re empty.

# Check tunnel connections in relay logs
kubectl -n agents logs deploy/vk-remote -c relay-server --tail=30

If no tunnel connections appear:

The local VibeKanbanThe task board Frank dispatches agent work through — the queue between a written plan's phases and the agents that execute them. server (secure-agent-pod) may not be running — check kubectl -n secure-agent-pod get pods.
VK_SHARED_RELAY_API_BASE may not be set — check the env var.
Cilium NetworkPolicy may block egress to vk.cluster.derio.net.

Pairing Code Rejected

Code expired (6-digit codes are short-lived — generate a fresh one).
Browser and local server not on the same relay — verify both point to vk.cluster.derio.net.
Simple Password-Authenticated Key ExchangeA protocol that turns a short shared code into a strong mutual key without exposing the code to eavesdroppers. The enrolment codes are single-use — "please sign in again" usually means it was already spent. key mismatch — regenerate and retry.

Container Not at 2/2 Ready

If only one container is Running:

kubectl -n agents logs deploy/vk-remote -c <missing-container>
kubectl -n agents describe pod -l app=vk-remote

Missteps

What we assumed	Why it was wrong	What it cost
The relay and vk-remote can share a single container	Each has different lifecycle and routing needs. The relay needs its own readiness probe and port.	Split into two containers in the same pod.
A pairing code is valid until the browser closes it	Codes are short-lived by design (SPAKE2 handshake timeout). A stale UI showing an old code wastes a pairing attempt.	Added a “generate new code” instruction to the re-pairing flow.
A 502 on the relay path is always a relay-server crash	It can also be a Traefik IngressRoute misconfiguration or a Cilium egress policy blocking the WebSocket upgrade.	Added the three-layer diagnosis to the runbook.

Quick Reference

Command	What It Does
`kubectl -n agents get pods -l app=vk-remote`	Pod status (expect 2/2)
`kubectl -n agents logs deploy/vk-remote -c relay-server`	Relay server logs
`curl -s -o /dev/null -w "%{http_code}" https://vk.cluster.derio.net/v1/relay/connect`	Endpoint test (expect 401)
`kubectl -n agents rollout restart deploy/vk-remote`	Restart relay
`kubectl -n secure-agent-pod port-forward deploy/secure-agent-pod 8081:8081`	Local VK server (for pairing)
`kubectl -n secure-agent-pod exec deploy/secure-agent-pod -c kali -- env \| grep VK_SHARED_RELAY`	Check relay env var
