Operating on VK Remote

Last updated 2026-07-15 ·eff627f

This is the operational companion to VK Remote — Self-Hosting the Kanban Backend. That post explains the architecture. This one is the day-to-day runbook.

    graph TD
    subgraph agents["agents namespace"]
        pg["postgres-vk<br/>PostgreSQL<br/>wal_level=logical"]
        electric["electric<br/>ElectricSQL<br/>replication consumer"]
        vk["vk-remote<br/>API server<br/>port 8081"]

        init["init Job<br/>postgres-vk-init-electric"]

        pg -->|"logical replication"| electric
        electric -->|"shape sync"| vk
        init -.->|"creates electric role"| pg
    end

    subgraph svc["Service Layer"]
        lb["LoadBalancer<br/>Traefik ingress"]
        sso["Authentik SSO"]
    end

    subgraph users["Access"]
        browser["Browser<br/>vk.cluster.derio.net"]
        api["API client<br/>port-forward :8081"]
    end

    browser --> sso --> lb --> vk
    api --> vk

What Healthy Looks Like

Three pods in agents namespace: postgres-vk, electric, vk-remote — all Running.
The init Job postgres-vk-init-electric shows Completions: 1/1.
PostgreSQL wal_level is logical and the replication slot electric_slot_default is active.
vk-remote responds on port 8081 with a healthy API.
Browser access works at https://vk.cluster.derio.net through Authentik Single Sign-OnOne login across many applications. On Frank, Authentik holds the session and Traefik asks it before forwarding a request..

Verify

# Pods
kubectl -n agents get pods -l 'app in (postgres-vk, electric, vk-remote)'

# Init job
kubectl -n agents get jobs

# PostgreSQL replication
kubectl -n agents exec deploy/postgres-vk -- psql -U remote -d remote -c \
  "SELECT slot_name, active FROM pg_replication_slots;"
kubectl -n agents exec deploy/postgres-vk -- psql -U remote -d remote -c \
  "SHOW wal_level;"

# ElectricSQL
kubectl -n agents logs deploy/electric --tail=10

# vk-remote API
kubectl -n agents exec deploy/vk-remote -- wget -qO- http://localhost:8081/v1/health

$ kubectl -n agents get pods -l 'app in (postgres-vk, electric, vk-remote)'
NAME                              READY   STATUS      RESTARTS   AGE
electric-6c5f6487d7-prswg         1/1     Running     0          8d
postgres-vk-557b4b6b7-9xvwq       1/1     Running     0          8d
vk-remote-7949d8bb66-vpgpx        2/2     Running     0          21h
postgres-vk-init-electric-pgqzp   0/1     Completed   0          21h

Steps

Restart Any Component

kubectl -n agents rollout restart deploy/vk-remote
kubectl -n agents rollout status deploy/vk-remote

# Or for ElectricSQL
kubectl -n agents rollout restart deploy/electric
kubectl -n agents rollout status deploy/electric

PostgreSQL uses Recreate strategy (ReadWriteOnceA PVC access mode that lets exactly one node mount the volume read-write at a time. It is the reason a RollingUpdate deadlocks: the replacement pod cannot mount the volume until the outgoing pod releases it. PersistentVolumeClaimA Kubernetes request for durable storage. The pod names a claim and the storage layer — Longhorn on Frank — binds real disk behind it, so the data outlives the pod.) — expect brief downtime for the entire stack.

Login and Get a JWT Token

PASSWORD=$(kubectl -n agents get secret vk-remote-secrets \
  -o jsonpath='{.data.SELF_HOST_LOCAL_AUTH_PASSWORD}' | base64 -d)

kubectl -n agents port-forward svc/vk-remote 8081:8081 &
TOKEN=$(curl -s -X POST http://localhost:8081/v1/auth/local/login \
  -H 'Content-Type: application/json' \
  -d "{\"email\":\"admin@localhost\",\"password\":\"$PASSWORD\"}" | jq -r '.token')

List Orgs and Projects

curl -s -H "Authorization: Bearer $TOKEN" http://localhost:8081/v1/organizations | jq
curl -s -H "Authorization: Bearer $TOKEN" http://localhost:8081/v1/projects | jq

Recover

ElectricSQL Not Syncing

Symptom: the kanban board doesn’t update in real-time.

kubectl -n agents logs deploy/electric --tail=30

If connection errors:

Verify the electric PG role exists: kubectl -n agents exec deploy/postgres-vk -- psql -U remote -d remote -c "SELECT rolname FROM pg_roles WHERE rolname = 'electric';"
If missing, delete and re-trigger the init job: kubectl -n agents delete job postgres-vk-init-electric — ArgoCD will re-create it on next sync.
Restart ElectricSQL: kubectl -n agents rollout restart deploy/electric

Init Job Failed

kubectl -n agents logs job/postgres-vk-init-electric

Common: PostgreSQL wasn’t ready when the job ran — delete the job and let ArgoCD re-create it. Or password mismatch — check kubectl -n agents get externalsecret vk-remote-secrets.

502 on vk.cluster.derio.net

kubectl -n agents get pods -l app=vk-remote
kubectl -n agents logs deploy/vk-remote --tail=30

If CrashLoopBackOff:

Database connectivity — SERVER_DATABASE_URL uses variable substitution. If the Secret is missing, the env var resolves to an empty password.
Secret sync — kubectl -n agents get externalsecret vk-remote-secrets -o jsonpath='{.status.conditions}'

Authentik SSO Not Working

kubectl exec -n authentik deploy/authentik-server -- python -c "
import os; os.environ.setdefault('DJANGO_SETTINGS_MODULE','authentik.root.settings')
import django; django.setup()
from authentik.outposts.models import Outpost
outpost = Outpost.objects.get(name='authentik Embedded Outpost')
print([p.name for p in outpost.providers.all()])
"

If VK Remote (cluster) is not in the list, assign it:

kubectl exec -n authentik deploy/authentik-server -- python -c "
import os; os.environ.setdefault('DJANGO_SETTINGS_MODULE','authentik.root.settings')
import django; django.setup()
from authentik.providers.proxy.models import ProxyProvider
from authentik.outposts.models import Outpost
outpost = Outpost.objects.get(name='authentik Embedded Outpost')
provider = ProxyProvider.objects.get(name='VK Remote (cluster)')
outpost.providers.add(provider)
"

Cannot Login via API

Check:

Correct password: kubectl -n agents get secret vk-remote-secrets -o jsonpath='{.data.SELF_HOST_LOCAL_AUTH_PASSWORD}' | base64 -d
Correct email: must be admin@localhost
Database accessible — the login endpoint writes to PostgreSQL

Missteps

What we assumed	Why it was wrong	What it cost
The init job will always find PostgreSQL ready	The job runs as soon as ArgoCD syncs. If PG is still starting, the SQL migrations fail and the job exits non-zero.	Delete-and-retry loop for the init job until we made PG readiness explicit.
`SERVER_DATABASE_URL` with variable substitution safely handles empty secrets	If the ExternalSecret hasn’t synced, the env var becomes `postgres://remote:@postgres-vk:5432/remote` — no password means authentication failure.	Added a startup probe that checks DB connectivity before serving.
Authentik SSO works as soon as the blueprint is applied	The blueprint creates the provider, but it must also be assigned to the embedded outpost. Without the assignment, Authentik returns 404.	Added the outpost-assignment step to the on-boarding checklist.

Quick Reference

Command	What It Does
`kubectl -n agents get pods -l 'app in (postgres-vk, electric, vk-remote)'`	Stack status
`kubectl -n agents get jobs`	Init job status
`kubectl -n agents exec deploy/postgres-vk -- psql -U remote -d remote -c "SHOW wal_level;"`	PG replication config
`kubectl -n agents logs deploy/electric --tail=30`	ElectricSQL sync status
`kubectl -n agents exec deploy/vk-remote -- wget -qO- localhost:8081/v1/health`	API health
`kubectl -n agents rollout restart deploy/vk-remote`	Restart vk-remote
`kubectl -n agents delete job postgres-vk-init-electric`	Re-trigger init job
