Operating on Ruflo

This is the operational companion to Ruflo — A Swarm Orchestrator Next to Paperclip. That post explains the architecture and the rationale. This one covers the day-to-day: connecting, installing tools, bumping images, reading logs, recovering from breakage, and a worked swarm-run cookbook.

What “Healthy” Looks Like

Ruflo is healthy when:

The ruflo Deployment is 2/2 Running in the ruflo-system namespace (both ruflo and ruflo-shell containers Ready).
The web UI loads at https://ruflo.cluster.derio.net after Authentik SSO.
SSH to agent@192.168.55.222 succeeds.
All four ExternalSecrets (ruflo-llm, ruflo-resend, ruflo-shell-alerts, plus any optional add-ons) show SecretSynced=True.
The three PVCs are Bound (ruflo-data 5Gi, ruflo-shell-home 10Gi, ruflo-workspace 20Gi).
The ruflo-db Bitnami postgresql StatefulSet is 1/1 Running (parked but green — see the building post for the RVF deviation).

kubectl get pods,pvc,externalsecret,svc -n ruflo-system

Expected: one ruflo-… Deployment pod (2/2), one ruflo-db-postgresql-0 StatefulSet pod (2/2), three Bound PVCs, four synced ExternalSecrets, two Services (ClusterIP for ruvocal, LoadBalancer at 192.168.55.222 for SSH+Mosh).

Connecting

Web UI

Open https://ruflo.cluster.derio.net. Authentik forward-auth handles the SSO redirect. After login you land on ruvocal’s chat surface. The session cookie is shared with every other Authentik-fronted service on the cluster, so you sign in once.

SSH

Add to ~/.ssh/config:

Host ruflo
  HostName 192.168.55.222
  User agent
  Port 22

Then:

ssh ruflo

Mosh

Mosh works over a UDP port range allocated on the Service (60016–60031). You can wrap it in a shell function or just call it directly:

mosh --ssh="ssh -i ~/.ssh/<your-key>" \
     --server="mosh-server new -p 60016:60031" \
     agent@192.168.55.222

Sixteen ports is plenty of headroom; MOSH_SERVER_NETWORK_TMOUT reaps stuck sessions so the range doesn’t bleed.

Authorised-Keys Bootstrap

Authorised keys live in a SOPS-encrypted Secret ruflo-shell-ssh-keys (under secrets/ruflo/). The pod boots whether the Secret exists or not — sshd just rejects key-based logins until the bootstrap is applied. To rotate or seed keys:

# Edit secrets/ruflo/ruflo-shell-ssh-keys.yaml (SOPS will round-trip the encryption)
sops secrets/ruflo/ruflo-shell-ssh-keys.yaml

# Apply
sops -d secrets/ruflo/ruflo-shell-ssh-keys.yaml | kubectl apply -f -

If the pod was running before the bootstrap landed, the cont-init.d/30-authorized-keys hook only fires at boot — so the new keys won’t be live until you trigger a re-copy:

kubectl exec -n ruflo-system deploy/ruflo -c ruflo-shell -- \
  bash -c 'cp /etc/ssh-keys/authorized_keys "${AGENT_HOME:-/home/agent}/.ssh/authorized_keys" \
           && chmod 600 "${AGENT_HOME:-/home/agent}/.ssh/authorized_keys"'

Or just kubectl rollout restart deploy/ruflo -n ruflo-system and let cont-init.d re-fire on the new pod. (The same hook bites every shell sidecar — there’s a frank-gotchas entry for it.)

Adding and Removing Tools

The shell sidecar’s tool inventory is declarative — apps/ruflo/manifests/configmap-shell-inventory.yaml:

data:
  inventory.yaml: |
    mise:
      - python@3.12
      - node@20
      - rust@stable
    npm-global:
      - "claude-flow@alpha"
      - "@openai/codex"
    pipx:
      - black
      - ruff
    cargo:
      - ripgrep
      - eza
    removed:
      mise: []
      npm-global: []
      pipx: []
      cargo: []

Edit, commit, push. ArgoCD syncs the ConfigMap. The boot-time reconciler picks up the new declaration on the next pod restart and installs/removes accordingly. To trigger immediately without a restart:

ssh ruflo -- ruflo-shell-reconcile

The `removed:` Arrays

Removing a tool from the upper arrays does NOT uninstall it — that’s intentional, so removing a declaration doesn’t surprise an in-flight session. To actively uninstall, add the tool to the matching removed: list:

removed:
  cargo: [eza]   # forces `cargo uninstall eza` on next reconcile

Once reconcile runs and reports the removal, you can drop the entry from removed: (or leave it as a record).

Interactive Installs (Layer-3 Escape Hatch)

For discovery work, just install on the pod — mise install, npm i -g, pipx install, cargo install. All four managers persist their state under ${AGENT_HOME} (i.e. /home/agent/{.local/share/mise, .cargo/bin, .local/pipx, .local/share/mise/installs/node/20.../lib}) which is mounted from the ruflo-shell-home PVC. Tools survive pod bounces.

ssh ruflo -- cargo install fd-find
kubectl rollout restart deploy/ruflo -n ruflo-system
ssh ruflo -- which fd     # /home/agent/.cargo/bin/fd — survived the bounce

When to Promote to the Inventory

Promote an interactive install when:

You want the tool to survive a PV migration (the inventory ConfigMap is the source of truth — interactive installs are in PV state).
You want the next operator (or a freshly recreated PVC) to inherit the tool.
You want the boot-time reconcile and the Telegram-on-failure alert path to cover it.

Otherwise leave it interactive. Discovery week is meant to lean on this.

The mise-Activation Workaround (Pending Upstream Fix)

install-inventory.sh in the current agent-shell-base has a known bug: after mise install <tool>, it doesn’t run mise use --global <tool>, so subsequent steps that resolve npm / python fall through to the system installs and fail (EACCES on /usr/lib/node_modules/, missing pyyaml, etc.). Workaround on the live pod:

ssh ruflo -- 'mise use --global node@20 rust@stable python@3.12'
ssh ruflo -- 'mise exec -- pip install pyyaml'
ssh ruflo -- ruflo-shell-reconcile      # re-run after activation

The fix belongs in agent-shell-base. Once it ships, this workaround goes away.

Reading the Install Log

Every reconcile run writes a per-tool log to /var/log/cont-init.d/install-inventory.log and a one-line MOTD summary to /run/motd.dynamic. The next SSH login sees the summary on the banner:

✓ ruflo-shell: 7 installed, 0 already present, 0 removed @ 2026-05-03T14:22:11Z

A failed=N count flips the banner to a warning glyph and triggers a Telegram alert via the ruflo-shell-alerts ExternalSecret. The alert contains the tool, the manager, the exit code, and the last 40 lines of the install log. Recovery flow:

ssh ruflo
sudo less /var/log/cont-init.d/install-inventory.log    # full log
ruflo-shell-reconcile                                   # re-try after fixing

If the Telegram alert path is silent on a known failure, check: (a) the ruflo-shell-alerts Secret exists and is SecretSynced=True; (b) the notify-telegram.sh helper is on PATH on the pod; (c) FRANK_C2_TELEGRAM_BOT_TOKEN and FRANK_C2_TELEGRAM_CHAT_ID exist in Infisical.

Bumping Images

`ruflo-shell` (Layer-1 changes)

Bump the ruflo-shell image when you want to change something baked at build time — i.e. anything that lives outside ${AGENT_HOME}. Examples: a new tool that should live in /usr/local/bin, an s6 service unit, a cont-init.d hook fix, an MOTD template change.

The image is built by the derio-net/agent-images matrix CI. Workflow:

Land the change in the agent-images repo (PR against main).
CI builds and pushes ghcr.io/derio-net/ruflo-shell:<short-sha>.
The lockstep bumper opens a PR in frank updating apps/ruflo/manifests/deployment.yaml to the new SHA.
Merge → ArgoCD syncs → Deployment rolls.

`ruflo-server` (upstream ruvocal)

The ruflo-server image is a thin wrapper around ruvnet/ruflo at a pinned upstream SHA. To bump:

Edit agent-images/ruflo-server/Dockerfile — change the RUFLO_UPSTREAM_SHA=… build arg.
CI rebuilds; new tag ghcr.io/derio-net/ruflo-server:<short-sha>.
Lockstep bumper PR in frank.

Read the upstream changelog before bumping — ruvocal has had a few “the data layer is now …” surprises (Mongo → RVF/Postgres). If DATABASE_URL start being honored at a new SHA, drop the parked ruflo-db and migrate state out of the RVF JSON file before flipping the image.

When to Add to the Inventory Instead

If the change is “a new CLI tool the operator wants on the shell,” prefer the inventory ConfigMap over rebuilding ruflo-shell. Inventory edits are PR-and-sync; image bumps are PR-build-PR-sync. Bake into the image only when:

The tool needs to live in /usr/local/bin (root-owned, system-wide).
The tool has heavy dependencies you don’t want to install on every pod re-create.
The tool participates in the s6/cont-init.d lifecycle.

Everything else: inventory.

Backup and Recovery

Three Longhorn-backed PVCs:

PVC	Size	Holds
`ruflo-data`	5Gi	RVF JSON store (`/app/db/ruvocal.rvf.json` + indices)
`ruflo-shell-home`	10Gi	mise installs, cargo bin, pipx, claude-flow CLI state, dotfiles
`ruflo-workspace`	20Gi	shared between containers; project checkouts, scratch space

Plus the ruflo-db StatefulSet’s PVC (20Gi, parked).

Cluster-wide recurring backup policy applies (see Operating on Storage & Backups). Schedule, retention, and offsite (Cloudflare R2) target are inherited from the cluster default.

To restore a single PVC:

# 1. Scale Deployment to 0
kubectl scale deploy/ruflo -n ruflo-system --replicas=0

# 2. Delete the PVC
kubectl delete pvc ruflo-data -n ruflo-system

# 3. In Longhorn UI (192.168.55.201) → Volumes → ruflo-data backup → Restore
#    Restore as PVC named `ruflo-data` in namespace `ruflo-system`.

# 4. Scale back up
kubectl scale deploy/ruflo -n ruflo-system --replicas=1

The ruflo-data PVC is the one to back up religiously — it holds every hive, run, and conversation. The other two are reproducible from declarative state (image + inventory ConfigMap + git).

Swarm-Run Cookbook

Corrected 2026-06-05, after the first real end-to-end attempt. The original version of this section described a claude-flow orchestrate --hive hive.yaml flow that does not exist in the v3 CLI (ruflo v3.10.x), and an env block that belongs to the ruvocal container, not the shell sidecar. What follows is what actually works — discovered the honest way, by running it.

Three facts to internalize before the recipe:

claude-flow swarm/hive-mind build coordination state only — topologies, message bus, task queues, consensus. The workers that do the actual work are Claude Code processes (hive-mind spawn --claude / claude -p). No authenticated claude CLI on the shell = swarms that initialize beautifully and execute nothing.
Worker tokens bill Anthropic, not LiteLLM. The zero-direct-key, local-only posture covers ruvocal’s chat surface; claude-flow workers ride the claude CLI’s own auth (subscription OAuth or ANTHROPIC_BASE_URL override — see the local-models note below).
Always use login shells over SSH (ssh ruflo interactive, or ssh ruflo 'bash -lc ...'). sshd scrubs container env and only login shells get the /etc/profile.d/ shims that put the mise-managed claude-flow on PATH. ssh ruflo -- cmd silently sees neither.

One-time prerequisite (persists on the ruflo-shell-home PVC):

ssh ruflo
claude          # then /login — subscription OAuth via browser

The recipe:

ssh ruflo

# 1. Sanity checks.
claude-flow --version             # ruflo v3.10.x
claude-flow status                # reaches ruvocal at localhost:3000; [STOPPED] pre-run is normal
claude -p "reply with exactly: AUTH-OK" --model haiku    # must print AUTH-OK

# 2. Work in a real directory — the swarm operates on cwd.
cd /workspace/projects/<repo>     # or a sandbox

# 3. Initialize coordination (cap agents — workers bill your subscription).
claude-flow swarm init -m 3
claude-flow swarm start -o "Rewrite README.md into a clean structured README and commit on branch swarm/readme" -s development
# prints agent slots, then tells you execution happens via Claude Code

# 4. Spawn the actual workers and hand them the task (queen-led variant):
claude-flow hive-mind init -t hierarchical-mesh
claude-flow hive-mind spawn --claude --count 2
claude-flow hive-mind task "Rewrite README.md ... commit on branch swarm/readme"

# 5. Watch.
claude-flow hive-mind status
claude-flow swarm status
# and the run shows up in the web UI at https://ruflo.cluster.derio.net

# 6. Clean up.
claude-flow hive-mind shutdown

The shell sidecar’s own env carries only LITELLM_BASE_URL — the OPENAI_API_KEY/OPENAI_BASE_URL pair lives in the ruvocal container and powers the chat surface, not the swarm workers.

Local models under the Claude Code harness? Possible in principle: claude honors ANTHROPIC_BASE_URL/ANTHROPIC_AUTH_TOKEN, and LiteLLM speaks the Anthropic /v1/messages format, so workers can be pointed at the local qwen lineup. Expect a real quality cliff — the Claude Code harness (tool schemas, thinking, edit discipline) is tuned for Claude-family models. Tracked as a future experiment, not part of this cookbook.

Common Operations

Restarting Ruflo

The Deployment uses strategy: Recreate (every container’s PVC is RWO). Rolling updates would deadlock — the new pod can’t mount any of the three volumes while the old pod holds them.

kubectl rollout restart deploy/ruflo -n ruflo-system
kubectl rollout status deploy/ruflo -n ruflo-system --timeout=120s

Expect ~30–60s of downtime while the new pod attaches the three PVCs and the s6 init in ruflo-shell finishes its cont-init.d chain. The web UI bounces; SSH connections drop.

Forcing a Reconcile Without a Restart

ssh ruflo -- ruflo-shell-reconcile

That re-reads the inventory and installs/removes against the current state on the ruflo-shell-home PVC. Useful after a ConfigMap edit when you don’t want to wait for a pod bounce.

Manually Driving the Database Tier (Parked Postgres)

The ruflo-db StatefulSet is parked but green — kept around in case a future re-vendor flips ruvocal’s data layer back to Postgres. Treat it as inert. If you need to confirm it’s alive:

kubectl exec -n ruflo-system ruflo-db-postgresql-0 -c postgresql -- \
  psql -U ruflo -d ruflo -c '\dt'

If you’re satisfied that the data layer will never flip back, the cleanup is: delete apps/ruflo-db/, delete its Application CR, drop the StatefulSet’s PVC. Out of scope for this layer.

Troubleshooting

Pod Stuck `0/2` or `1/2`

Both containers must reach Ready. Common causes:

ruflo container Pending or CrashLoopBackOff — most likely the LiteLLM virtual key is wrong (401 from upstream LiteLLM at boot) or the ruflo-data PVC is unwritable. Check:
```
kubectl logs -n ruflo-system deploy/ruflo -c ruflo --previous | tail -30
kubectl describe pvc ruflo-data -n ruflo-system
```
ruflo-shell container Init:Error — the s6-overlay v3 init refuses to start as non-pid-1. If you see s6-overlay-suexec: fatal: can only run as pid 1, check that shareProcessNamespace is not set on the Pod spec (it’s incompatible with agent-shell-base — see the building post and the gotchas file).
ruflo-shell container Running but sshd not answering — cont-init.d/30-authorized-keys short-circuited because the SOPS Secret wasn’t applied yet. Apply the Secret and follow the recovery in Connecting → Authorised-Keys Bootstrap.

502 from the Web UI

Traefik returns 502 when ruvocal’s /api/v2/feature-flags readiness probe is failing. The pod is up but the kubelet has marked it NotReady, so the Service has no endpoints.

kubectl get endpoints -n ruflo-system ruflo
kubectl describe pod -n ruflo-system -l app.kubernetes.io/name=ruflo

If the probe is failing, it’s almost always upstream — LiteLLM is down, OpenRouter is rate-limiting, or the LiteLLM virtual key has been revoked.

401 Loop on Model Calls (After a Working Boot)

The LiteLLM virtual key (RUFLO_LITELLM_KEY) was revoked or rotated in Infisical. The pod has the cached value; ESO re-syncs every 5 minutes. Force a re-sync:

kubectl annotate externalsecret ruflo-llm -n ruflo-system \
  force-sync=$(date +%s) --overwrite
kubectl rollout restart deploy/ruflo -n ruflo-system

Image / File Upload Returns 500

If attaching an image (or a tool fetching a file by URL) 500s with TypeError: upload.once is not a function — or uploads “succeed” but the image renders blank on re-open — the RvfGridFSBucket GridFS-shim parity fix is missing from the running bundle. This was fixed in ruflo-server 0ff7014 (frank #464); a regressed or pre-fix image brings it back.

# Confirm the fix is present in the deployed bundle:
kubectl -n ruflo-system exec deploy/ruflo -c ruflo -- \
  sh -c 'grep -l "objectMode: true" /app/build/server/chunks/database-*.js'
# expect a match. Then check live logs during an upload attempt:
kubectl -n ruflo-system logs deploy/ruflo -c ruflo --since=5m | \
  grep -E 'upload.once|ERR_INVALID_ARG_TYPE|is not a function' && echo PRESENT-BAD || echo CLEAN

If the grep finds no objectMode match, the deployed image predates the fix — bump apps/ruflo/manifests/deployment.yaml to a ruflo-server SHA ≥ 0ff7014. Note that no Frank model currently advertises multimodal:true, so the UI image-attach control is gated off; the upload path is exercised by tool-fetched files and the HTTP route, not the attach button. See the GridFS-shim section in docs/runbooks/frank-gotchas/paperclip-ruflo.md.

Telegram Alerts Stop

Check the alert ExternalSecret:

kubectl get externalsecret ruflo-shell-alerts -n ruflo-system
kubectl describe externalsecret ruflo-shell-alerts -n ruflo-system

The alert helper resolves FRANK_C2_TELEGRAM_BOT_TOKEN / FRANK_C2_TELEGRAM_CHAT_ID at send time. If those rotate in Infisical, ESO syncs the new values within 5 minutes.

Gotchas

shareProcessNamespace: true is incompatible with the shell sidecar. s6-overlay v3 must be pid 1 in its container’s namespace. Cross-container debugging goes through kubectl exec -c <other> instead.
/ is the wrong probe path. ruvocal SSR-renders the model list at request time, so probes against / are full upstream-dependency checks. Use /api/v2/feature-flags (already configured).
OPENAI_API_KEY must be a LiteLLM virtual key, not the OpenRouter key. LiteLLM authenticates against its own key store. Symptom of a wrong key: 401 on every model-list call, 500 on /.
The data layer is RVF, not Postgres. Mounting a PVC at /app/db is essential — without it, every restart starts from a fresh empty ruvocal.rvf.json and every hive vanishes.
RVF’s GridFSBucket is a shim — its file upload/download/copy-on-fork paths needed a parity fix (real Writable/Readable/cursor) to stop 500-ing. Carried as a build-time patch, upstreamed as ruvnet/ruflo#2293. A pre-fix image regresses file uploads (see Troubleshooting above).
mise install doesn’t activate. Until the upstream agent-shell-base fix lands, manual mise use --global … after first reconcile is required (see workaround above).
The cont-init.d/30-authorized-keys hook only fires at pod boot. Rotating SSH keys mid-life requires either a kubectl exec re-copy or a pod bounce.

References

Building Post: Ruflo — architecture and rationale
Building Post: Agent Images and the VK-Local Sidecar — the agent-shell-base lineage
Operating on Paperclip — the org-chart counterpart
Operating on Storage & Backups — Longhorn snapshot policy
ruvnet/ruflo — upstream
