Operating Edge Observability

Last updated 2026-07-15 ·2755dfd

The companion to Edge Observability. This post is the cheat-sheet for the night Grafana pages you with DatasourceError.

Assumes both .env (Frank) and .env_hop (Hop) are available. Sourcing the wrong one silently sends commands to the wrong cluster — the single most common mistake.

    graph TD
    subgraph hop["Hop Edge"]
        caddy["Caddy<br/>access logs"]
        cs_agent["CrowdSec Agent<br/>parses → decides"]
        falco["Falco<br/>syscall events"]
    end

    subgraph frank["Frank Cluster"]
        vlogs["VictoriaLogs<br/>monitoring namespace"]
        lapi["CrowdSec LAPI<br/>decisions"]
        goat["GoatCounter<br/>analytics"]
        grafana["Grafana<br/>Explore + Alerts"]
        digest["ai-alert-helper<br/>daily digest"]
    end

    caddy -->|"fluent-bit"| vlogs
    cs_agent -->|"decisions"| lapi
    cs_agent -->|"alerts"| vlogs
    falco -->|"fluent-bit"| vlogs
    lapi -->|"ban list"| caddy
    goat -->|"API token"| grafana
    vlogs -->|"datasource"| grafana
    digest -->|"Telegram"| user["You"]

What Healthy Looks Like

VictoriaLogs responds to queries in Grafana Explore — no DatasourceError.
CrowdSec shows active decisions and the bouncer is connected.
GoatCounter count.js returns 200 + ~8 KB at https://counter.derio.net/count.js.
Falco alerts are limited to genuine security events, not kube-system routine noise.
The daily digest arrives in Telegram on schedule.

Verify

# VictoriaLogs query (from within cluster)
kubectl exec -n monitoring vlogs-q -- curl -sG \
  'http://victoria-logs-victoria-logs-single-server.monitoring.svc:9428/select/logsql/query' \
  --data-urlencode 'query=_time:5m kubernetes.namespace_name:caddy-system' \
  --data-urlencode 'limit=5'

# CrowdSec decisions
kubectl exec -n crowdsec-system deploy/crowdsec-lapi -- cscli decisions list
kubectl exec -n crowdsec-system deploy/crowdsec-lapi -- cscli bouncers list

# GoatCounter public ingest
curl -s -o /dev/null -w 'count.js: %{http_code} size=%{size_download}\n' \
  https://counter.derio.net/count.js

# Fluent-bit logs reaching VictoriaLogs
_time:5m source:syscall | stats by (priority, rule) count() as c | sort by (c desc)

Steps

Query Blog Access Logs

# All blog requests, last 5 minutes
_time:5m kubernetes.namespace_name:caddy-system AND _msg:"handled request"

# 5xx responses, last hour
_time:1h kubernetes.namespace_name:caddy-system AND _msg:"handled request" AND status:>=500

# Top-N paths, last 24h
_time:24h kubernetes.namespace_name:caddy-system AND _msg:"handled request" \
  | stats by (request.uri) count() as hits | sort by (hits desc) | limit 10

Use the dotted field shape (kubernetes.namespace_name) — the underscore form returns zero hits.

Ban a Scraper

# Ban an IP for 4 hours
kubectl exec -n crowdsec-system deploy/crowdsec-lapi -- \
  cscli decisions add --ip 198.51.100.42 --duration 4h --reason "suspicious traffic"

# Ban a /16 range
kubectl exec -n crowdsec-system deploy/crowdsec-lapi -- \
  cscli decisions add --range 91.92.0.0/16 --duration 24h --reason "scraper farm"

# Unban
kubectl exec -n crowdsec-system deploy/crowdsec-lapi -- \
  cscli decisions delete --ip 198.51.100.42

Re-Register the Caddy Bouncer

If the bouncer drops after a Local APICrowdSec's local decision service. Agents report parsed events to it and bouncers ask it who to block — which means if its database is ephemeral, the whole ban pipeline silently does nothing. restart:

KEY=$(kubectl -n crowdsec-system get secret crowdsec-bouncer-keys \
  -o jsonpath='{.data.caddy-hop}' | base64 -d)
kubectl exec -n crowdsec-system deploy/crowdsec-lapi -- \
  cscli bouncers add caddy-hop -k "$KEY"

If both keys got de-synced, rotate both Secrets with the same new key.

Rotate GoatCounter API Token

# Create a new token
kubectl exec -n goatcounter-system deploy/goatcounter -- sh -c \
  "goatcounter db create apitoken \
    -db sqlite+/home/goatcounter/goatcounter-data/goatcounter.sqlite3 \
    -name grafana-readonly-$(date +%Y%m%d) -user 1 -perm count,export,site_read"

# Update the Grafana Secret
kubectl create secret generic grafana-goatcounter-token -n monitoring \
  --from-literal=OBS_GOATCOUNTER_API_TOKEN=<NEW> \
  --dry-run=client -o yaml | kubectl apply -f -
kubectl rollout restart -n monitoring deploy/victoria-metrics-grafana

Reset GoatCounter Bootstrap User

kubectl exec -n goatcounter-system deploy/goatcounter -- sh -c \
  "goatcounter db create site \
    -db sqlite+/home/goatcounter/goatcounter-data/goatcounter.sqlite3 \
    -vhost counter.cluster.derio.net \
    -user.email <email> -user.password '<strong-password>'"

Recover

Grafana `DatasourceError`

# Test VictoriaLogs directly
kubectl exec -n monitoring vlogs-q -- curl -sG \
  'http://victoria-logs-victoria-logs-single-server.monitoring.svc:9428/select/logsql/query' \
  --data-urlencode 'query=_time:1m' --data-urlencode 'limit=1'

If VictoriaLogs is up, the Grafana datasource config is stale — check victoria-logs-datasource.yaml in Grafana’s provisioning ConfigMap.

GoatCounter Public Ingest Down

Check in order:

# 1. From Hop — can Caddy reach the GoatCounter LB IP?
kubectl exec -n caddy-system deploy/caddy -- nc -vz 192.168.55.224 8080

# 2. Tailscale subnet routes
kubectl -n headscale-system exec ds/tailscale -- tailscale status | grep raspi

# 3. GoatCounter pod
kubectl -n goatcounter-system get pod

If enableServiceLinks: false is set on the pod, GoatCounter may fail to resolve its own SQLite path — a known regression.

Falco Too Noisy

Tune kube-system rules by editing the Falco Helm values and re-syncing:

# Check current alert rate
_time:1h source:syscall AND kubernetes.namespace_name:kube-system \
  | stats by (rule) count() as c | sort by (c desc)

Add exceptions for known patterns: Helm hooks, node problem detectors, Container Storage InterfaceThe plugin contract for storage, the counterpart to CNI. Longhorn is Frank's CSI driver: it turns a PVC into a real replicated volume. sidecars.

Missteps

What we assumed	Why it was wrong	What it cost
VictoriaLogs field names use underscores	Fluent-bit emits dotted `kubernetes.namespace_name` with `Merge_Log On`. Underscore-form queries return zero hits.	Burned an evening debugging empty query results.
CrowdSec LAPI decisions survive pod restarts on Hop	The LAPI pod uses `emptyDir` — no PersistentVolumeClaimA Kubernetes request for durable storage. The pod names a claim and the storage layer — Longhorn on Frank — binds real disk behind it, so the data outlives the pod.. Every restart wipes decisions and bouncer registrations.	Added `postStart` hook to re-register bouncer; manual fallback in the runbook.
The community blocklist works without enrollment	CrowdSec’s community blocklists require an `app.crowdsec.net` account and enrollment token. Without enrollment, only local scenarios apply.	Deferred — free-tier sign-up pending.
`enableServiceLinks: false` is safe for all pods	GoatCounter with `enableServiceLinks: false` can’t resolve its SQLite path via environment variable injection.	Debugging session to identify the regression.

Quick Reference

Command	What It Does
`cscli decisions list` (via kubectl exec)	Current bans
`cscli decisions add --ip <IP> --duration 4h`	Ban an IP
`cscli decisions delete --ip <IP>`	Unban an IP
`cscli bouncers list` (via kubectl exec)	Registered bouncers
`curl -s https://counter.derio.net/count.js \| wc -c`	GoatCounter liveness
`_time:5m source:syscall \| stats by (rule) count()`	Falco event rate by rule
`kubectl exec -n monitoring vlogs-q -- curl -sG ...`	Direct VictoriaLogs query
