Operating Automation — Day-to-Day Commands for AWX

The companion to /frank/docs/building/32-automation/. The building post is the story of standing AWX up; this one is the cheat-sheet for living with it — adding the next host, reading a job that went red, rotating the secret that fronts the whole thing, and the break-glass path for the day Authentik is down and the SSO button can’t save you.

Assumes the layer is deployed and .env (Frank KUBECONFIG) is sourced. AWX lives in the awx namespace; its UI is awx.cluster.derio.net.

Onboard a new host

This is the whole reason the layer exists, and it’s been reduced to an env file plus three scripts — the awx-onboard-hosts skill. Fill scripts/tmp/awx-hosts.env (one line per host: ssh_alias | awx_host | ansible_user | become), then:

bash agents/skills/awx-onboard-hosts/01-key-onboard.sh   # dedicated key + ssh-copy-id, verified the AWX way
bash agents/skills/awx-onboard-hosts/02-wire-up.sh       # org, credential, inventory + ad-hoc ping proof
bash agents/skills/awx-onboard-hosts/03-formalize.sh     # Gitea ping repo + Project + Job Template

The one preflight that actually matters runs first inside those scripts but is worth knowing by hand: can a pod even reach the host? AWX runs jobs in execution- environment pods on the cluster network, so a target on a different VLAN has to be routable from a pod, not just from your Mac:

kubectl -n awx exec deploy/awx-task -c awx-task -- \
  python3 -c "import socket;s=socket.socket();s.settimeout(4);s.connect(('192.168.10.14',22));print('OPEN')"

OPEN means feasible. A timeout means stop and fix routing before touching AWX.

Verify the two-layer reconcile

AWX is reconciled by two loops — ArgoCD installs the operator + CR; the operator builds the pods, DB, and migrations. ArgoCD Synced/Healthy only proves the first. To prove the second, look at the pods directly:

kubectl -n awx get awx awx -o jsonpath='{.status.conditions}'; echo
kubectl -n awx get pods
# expect: awx-postgres-15-0 Running, awx-web + awx-task Running, migration job Completed
kubectl -n awx logs deploy/awx-task -c awx-task | grep -i "migration"   # "...is finished"
curl -s https://awx.cluster.derio.net/api/v2/ping/ | python3 -m json.tool

If awx-web is CrashLooping right after a CR change, the first suspect is extra_settings: a string value missing its inner Python quotes is a syntax error in the rendered settings module. Check the rendered config:

kubectl -n awx get cm awx-awx-configmap -o jsonpath='{.data.settings}' | grep SOCIAL_AUTH

Run a job, read a failed job

Launch the smoke template (or any) from the UI, or by API. Per-host results and the full stdout are the truth:

ADMIN_PW=$(kubectl -n awx get secret awx-admin-password -o jsonpath='{.data.password}' | base64 -d)
# launch smoke-ping (job template id from the UI URL or the API)
kubectl -n awx exec deploy/awx-web -c awx-web -- \
  curl -s -u "admin:$ADMIN_PW" -X POST http://localhost:8052/api/v2/job_templates/<id>/launch/
# read a job's output
kubectl -n awx exec deploy/awx-web -c awx-web -- \
  curl -s -u "admin:$ADMIN_PW" "http://localhost:8052/api/v2/jobs/<job-id>/stdout/?format=txt"

A green run ends in PLAY RECAP … ok=N failed=0. unreachable=1 is an SSH/routing problem (re-run the pod reachability check above and confirm the machine credential’s key is the one you ssh-copy-id’d). failed=1 is the playbook itself — read the task that failed, not the recap.

Rotate / re-set the OIDC secret

The single most counter-intuitive operation here, because it has two traps stacked. The provider’s client_secret is auto-generated by Authentik — you don’t mint one, you copy Authentik’s into AWX. And it must be PATCHed into the oidc settings category, not authentication (the wrong category returns 200 and silently drops the key). The whole thing, idempotent:

ADMIN_PW=$(kubectl -n awx get secret awx-admin-password -o jsonpath='{.data.password}' | base64 -d)
SECRET=$(kubectl exec -n authentik deploy/authentik-worker -- python -c '
import os; os.environ.setdefault("DJANGO_SETTINGS_MODULE","authentik.root.settings")
import django; django.setup()
from authentik.providers.oauth2.models import OAuth2Provider
print(OAuth2Provider.objects.get(client_id="awx").client_secret)')
kubectl -n awx exec deploy/awx-web -c awx-web -- curl -s -u "admin:$ADMIN_PW" \
  -X PATCH http://localhost:8052/api/v2/settings/oidc/ \
  -H 'Content-Type: application/json' \
  -d "{\"SOCIAL_AUTH_OIDC_SECRET\": \"$SECRET\"}"

Verify it took — a successful write reads back as $encrypted$ , and the backend registers:

kubectl -n awx exec deploy/awx-web -c awx-web -- curl -s -u "admin:$ADMIN_PW" \
  http://localhost:8052/api/v2/settings/oidc/ | grep -o '"SOCIAL_AUTH_OIDC_SECRET":"[^"]*"'
curl -s https://awx.cluster.derio.net/api/v2/auth/    # should list an "oidc" login URL

If /api/v2/auth/ returns {}, the OIDC backend isn’t registered — the secret didn’t stick (wrong category) or the provider doesn’t exist (blueprint failed; see below).

When SSO itself is broken — break-glass admin

SSO is great until the thing you log in through is the thing that’s down. The local admin is the deliberate escape hatch and never goes through Authentik:

kubectl -n awx get secret awx-admin-password -o jsonpath='{.data.password}' | base64 -d; echo
# log in at awx.cluster.derio.net via the username/password form (not the SSO icon)

If the SSO button is missing entirely, the provider blueprint failed to apply — the classic being the Authentik 2026.x schema change. Check the blueprint instance:

kubectl exec -n authentik deploy/authentik-worker -- python -c '
import os; os.environ.setdefault("DJANGO_SETTINGS_MODULE","authentik.root.settings")
import django; django.setup()
from authentik.blueprints.models import BlueprintInstance
b=BlueprintInstance.objects.filter(name="AWX OIDC Provider").first()
print(b.status, bool(b.last_applied_hash))'   # want: successful True

error means the blueprint is invalid for the running Authentik version — fix the blueprint (invalidation_flow + object-shaped redirect_uris on 2026.x), let ArgoCD re-sync, and the worker re-applies.

Backup and restore

Two things hold the irreplaceable state. The bootstrap secrets (admin password, Django secret key) live SOPS-encrypted in secrets/awx/ and are applied out-of-band — restore with:

sops --decrypt secrets/awx/awx-admin-password.yaml | kubectl apply -f -
sops --decrypt secrets/awx/awx-secret-key.yaml     | kubectl apply -f -

The AWX database (inventories, credentials, job history) lives on the operator- managed Postgres PVC data-awx-postgres-15-0. It is not yet snapshotted — flagged as out-of-scope until AWX holds state worth the backup plumbing. When it does, that PVC is the target, not the awx app’s other volumes.

Gotchas, in increasing order of mean time to surprise

Synced/Healthy is the operator’s, not AWX’s. Always read the pods.
ansible_ssh_common_args is banned in ad-hoc extra_vars (AWX denylist) — put host-key options on the inventory as a variable instead.
Settings PATCH to the wrong category returns 200 and drops the key. Re-read the setting; don’t trust the status code.
An OIDC user lands with no RBAC. SSO authenticates; it doesn’t authorize. Map Authentik groups to AWX teams/roles, or do admin work as break-glass admin.
The auto-generated secret is per-provider. Recreate the Authentik provider and the secret changes — re-run the rotate block above; don’t hand-copy an old value.

What this doesn’t cover

Building actual automation content — real playbooks, surveys, schedules, workflow job templates, RBAC mapping from Authentik groups to AWX teams. The layer ships the controller and proves it reaches a host; the inventory of useful plays grows in-app from here.

References

Building post: /frank/docs/building/32-automation/
Onboarding skill: agents/skills/awx-onboard-hosts/
Runbook manual-ops: docs/runbooks/manual-operations.yaml (auto-awx-bootstrap-secrets, auto-awx-oidc-client-secret)
App + CR: apps/awx/
