Operating the Hermes Shell With Its Hindsight Memory Sidecar

Last updated 2026-07-27 ·4541ee6

Companion to Rebuilding the Hermes Shell. The pod is now three containers: hermes, ssh, and hindsight. Most of what changed is the memory sidecar — a supervised PostgreSQL + Hindsight process on an isolated PVCPersistentVolumeClaimA Kubernetes request for durable storage. The pod names a claim and the storage layer — Longhorn on Frank — binds real disk behind it, so the data outlives the pod..

    graph LR
    subgraph pod["hermes-agent-shell pod (gpu-1)"]
        hermes["hermes container<br/>bare official image<br/>gateway run"]
        sshc["ssh container<br/>sshd + mosh<br/>192.168.55.226"]
        hindsight["hindsight container<br/>PostgreSQL :5433<br/>Hindsight API :8888"]

        hermes ---|"memory queries"| hindsight
    end

    subgraph storage["PVCs"]
        data["hermes-agent-shell-data"]
        home["hermes-agent-shell-home"]
        repos["hermes-agent-shell-repos"]
        hmem["hermes-agent-shell-hindsight<br/>isolated memory PVC"]
    end

    hindsight --- hmem
    hindsight -->|"Longhorn recurring backup"| backup["Longhorn Snapshots"]
    hindsight -.->|"pg_dump -Fc"| portable["Portable dump file"]

    subgraph auth["Authentication"]
        sso["Authentik SSO<br/>dashboard route"]
        claude["Claude session<br/>(retain auth)"]
    end

    hermes --> sso
    hindsight -.-> claude


What Healthy Looks Like

• One pod Running on gpu-1, all three containers Ready.
• SSH/Mosh Service at 192.168.55.226 (TCP 22 + UDP 60032–60047).
• Hindsight /health returns {"status":"healthy","database":"connected"}.
• memory_units count in PostgreSQL is the expected value (369).

Verify

# Pod status
kubectl -n hermes-agent-shell get pods,svc,pvc

# Hindsight health
kubectl exec -n hermes-agent-shell -c hindsight deploy/hermes-agent-shell -- \
  curl -sf http://127.0.0.1:8888/health

# Agent-facing memory status
kubectl exec -n hermes-agent-shell -c hermes deploy/hermes-agent-shell -- \
  bash -lc 'hermes memory status'

# Memory count from PostgreSQL
kubectl exec -n hermes-agent-shell -c hindsight deploy/hermes-agent-shell -- \
  psql -h 127.0.0.1 -p 5433 -U hindsight -d postgres \
  -tAc 'select count(*) from memory_units'

Steps

Connect via SSH

ssh agent@192.168.55.226

mosh --ssh="ssh agent@192.168.55.226" \
     --server="mosh-server new -p 60032:60047" 192.168.55.226

Back Up Memory

Tier 1 — Longhorn snapshots (automatic via recurring backup group on the hindsight PVC).

Tier 2 — Portable logical dump:

kubectl exec -n hermes-agent-shell -c hindsight deploy/hermes-agent-shell -- \
  pg_dump -h 127.0.0.1 -p 5433 -U hindsight -Fc postgres > hindsight-$(date +%F).dump

Restore Memory

# On the old data directory (Postgres refuses group-readable dir):
chmod 700 "$OLD_PGDATA"

# Stand up old PG → pg_dump -Fc → pg_restore --clean --if-exists into 127.0.0.1:5433
# Restart pod, then verify:
kubectl exec -n hermes-agent-shell -c hindsight deploy/hermes-agent-shell -- \
  psql -h 127.0.0.1 -p 5433 -U hindsight -d postgres \
  -tAc 'select count(*) from memory_units'
# Expected: 369

Recover

hermes Container CrashLoops

kubectl -n hermes-agent-shell logs deploy/hermes-agent-shell -c hermes --tail=30

Missing args: ["gateway","run"] — the bare entrypoint runs an interactive TUIText User InterfaceA full-screen interface drawn in the terminal. Interactive like a GUI, which is why such tools do not compose with piped, non-interactive automation.. Ensure the manifest sets the gateway args. If chown-related: chown -R hermes:hermes /opt/data.

hindsight CrashLoops After Restart

kubectl -n hermes-agent-shell logs deploy/hermes-agent-shell -c hindsight --tail=30

fsGroup: 1000 re-loosens PGDATA to group-rwx on remount; Postgres refuses wider than 0750. The fix (chmod 700 $PGDATA on every boot) is baked into the sidecar’s start script.

Pod Flapping / Readiness Probe Fails

kubectl -n hermes-agent-shell describe pod -l app=hermes-agent-shell | grep -A 10 Events

hindsight-api binds 127.0.0.1 only — an httpGet probe against the pod IP draws connection-refused. The fix is exec probes that curl loopback, plus a startupProbe for the cold start.

Recall Works, Retain Doesn’t

Retain’s claude-code provider needs an authenticated Claude session in the hindsight sidecar. claude --version only proves the binary exists.

# Check if the session is authenticated
kubectl -n hermes-agent-shell exec -c hindsight deploy/hermes-agent-shell -- \
  bash -lc 'claude status 2>&1 | grep -i "logged\|authenticated\|session"'

If not authenticated, log in: kubectl exec -it -n hermes-agent-shell -c hindsight deploy/hermes-agent-shell -- claude and complete the OAuth flow. Recall (local BAAI/bge-small-en-v1.5 embeddings) is unaffected — it works without any LLMLarge Language ModelA model trained to predict text, served behind a chat or completion endpoint. On Frank these run locally on the GPU node rather than against a hosted provider. auth.

The Tool-Home Volume Fills

hermes-agent-shell-home is $HOME for every container, mounted at /opt/data/home. It reached 100% on 2026-07-27, which failed a fresh fr worktree checkout with No space left on device. Nothing alerted — there is still no PVC capacity rule.

It is not a dotfile volume, which is how it came to be sized at 20Gi. Measured at 19G used:

.local/opt/hermes-agent   6.0G   the PVC-resident Hermes venv
.vscode-server            3.3G
.cache                    1.9G   playwright, uv, huggingface, pip, fr
.local/{micromamba,share} 2.5G   mise, mamba, uv, claude
worktrees                 1.3G   fr isolation checkouts

Growth is dominated by tool installs and caches — the worktrees that exposed it are ~7%. So prune caches before reaching for more capacity:

# -x matters: `repos` is a SEPARATE PVC mounted inside home, so du double-counts without it
kubectl -n hermes-agent-shell exec -c ssh deploy/hermes-agent-shell -- \
  du -xh -d 2 /opt/data/home | sort -h | tail -25

The volume was expanded 20Gi → 40Gi (apps/hermes-agent-shell/manifests/pvc-home.yaml, guarded by scripts/tests/test_hermes_agent_shell_home_pvc.py). If you expand it again, check Longhorn provisioning headroom first — the ceiling counts declared replica size, not bytes written, and refuses silently. See Storage and Backups and Operating on Green.

Missteps

Quick Reference

References

• Building Post — Hermes Shell
• willikins#285 — official-image migration
• docs/runbooks/frank-gotchas/agent-shells.md — restore mechanic detail
• Operating on Local Inference
• Operating on Green — four ways a green tile diverges from reality
