Operating the Metrics API — kubectl top, HPAs, and the Silent-Empty Failure

Last updated 2026-08-03

metrics-server serves the resource Metrics API (metrics.k8s.io) on Frank. It runs as a single Deployment in kube-system, managed by ArgoCD. This is the companion reference to The Metrics API: the commands you actually run day to day.

One kubectl top answer travels four hops. Each check in Verify cuts the chain at a different point, which is what makes them worth running in order:

    flowchart TD
  C["kubectl top<br/>HPA controller"]
  AGG["aggregation layer<br/>APIService v1beta1.metrics.k8s.io"]
  MS["metrics-server<br/>Deployment, kube-system, 1 replica"]
  K["kubelet on each of 7 nodes<br/>:10250 HTTPS"]

  C --> AGG
  AGG --> MS
  MS -->|"polls /stats/summary"| K

  V1["1. get apiservice<br/>is a backend registered?"] -.-> AGG
  V2["2. get pods -l ...<br/>is the process up?"] -.-> MS
  V3["3. kubectl top nodes<br/>does the path answer?"] -.-> C
  X["x509 in the logs<br/>this hop is being rejected"] -.-> K


The building companion carries the architecture diagram — why this path exists at all, and the option that was rejected. This one is for finding which hop is broken.

What Healthy Looks Like

• v1beta1.metrics.k8s.io reads AVAILABLE=True.
• One metrics-server pod in kube-system, 1/1 Running.
• kubectl top nodes prints seven rows with non-zero CPU and memory.
• Every HPAHorizontalPodAutoscalerThe controller that adds and removes pod replicas based on a metric. It needs a metrics API to be serving, which is a separate component from the monitoring stack. on the cluster reports a real percentage in TARGETS, not <unknown>.

Pod readiness is deliberately not on that list. Ready means the pod’s own probe passed; it says nothing about whether kubelet scrapes are succeeding. The third bullet is the real signal.

Verify

Three checks, cheapest first. Output captured 2026-08-03.

1. Is a backend registered, and is it answering?

$ kubectl get apiservice v1beta1.metrics.k8s.io
NAME                     SERVICE                      AVAILABLE   AGE
v1beta1.metrics.k8s.io   kube-system/metrics-server   True        9d

NotFound means nothing serves the API at all, and kubectl top will say error: Metrics API not available. AVAILABLE=False is a different problem — something is registered but not answering, so go to check 2. Expect False for roughly the first 30 seconds after a deploy or a restart, while the first scrape window lands.

2. Is the process up?

$ kubectl -n kube-system get pods -l app.kubernetes.io/name=metrics-server
NAME                              READY   STATUS    RESTARTS      AGE
metrics-server-6d9fff4668-8g9vc   1/1     Running   6 (14h ago)   9d

3. Does the whole path answer?

$ kubectl top nodes
NAME      CPU(cores)   CPU(%)   MEMORY(bytes)   MEMORY(%)
gpu-1     1325m        4%       24260Mi         18%
mini-1    394m         2%       9192Mi          14%
mini-2    989m         7%       15257Mi         24%
mini-3    693m         4%       9002Mi          14%
pc-1      434m         10%      4982Mi          15%
raspi-1   528m         13%      1694Mi          51%
raspi-2   628m         15%      1893Mi          57%

Seven rows with real numbers means everything downstream works — kubectl top pods, and every HPA on the cluster.

Two checks are deliberately not repeated here: reading the rendered arg list to prove --kubelet-insecure-tls is live, and asking an HPA’s .status.conditions whether the controller (not just a human) can read the API. Both belong to the deploy-time path and are in the building companion’s Verifying the Metrics API section. Use them when you have just changed the values file; use the three above when something has gone quiet.

Steps

Add a CPU or memory HPA

The common case. The target Deployment must declare CPU (or memory) requests — the HPA computes utilization as a percentage of the request, so with no request it cannot compute anything and TARGETS stays <unknown>.

kubectl autoscale deployment <name> -n <ns> --cpu=70% --min=1 --max=4

Then read it back. Frank ships exactly one HPA, on the Tekton webhook, and it is the reference for what a working one looks like:

$ kubectl get hpa -A
NAMESPACE          NAME                       REFERENCE                             TARGETS         MINPODS   MAXPODS   REPLICAS   AGE
tekton-pipelines   tekton-pipelines-webhook   Deployment/tekton-pipelines-webhook   cpu: 18%/100%   1         5         1          126d

A real percentage is the pass; <unknown>/100% means the Metrics API is not serving that workload’s pods. The 18% is a dated sample and nothing more — the same command read cpu: 1% on 2026-08-01 and 2% later the same day. The command is the durable artefact, the digit is weather.

For anything ArgoCD-managed, declare the HPA in git rather than imperatively, and add an ignoreDifferences on /spec/replicas for the target Deployment so ArgoCD and the HPA do not fight over the replica count.

Note: this is CPU/memory autoscaling only. Scaling on custom metrics (queue depth, RPSRequests Per SecondThroughput measured at the edge. Frank's own uptime probe contributes a steady background rate, which has to be excluded before a surge means anything., tokens/s) needs a separate adapter that Frank does not run yet — tracked in #701. metrics-server serves metrics.k8s.io and nothing else.

The failure mode: pod Ready, top empty

This is the one that wastes an afternoon. kubectl top nodes returns error: Metrics API not available or empty rows, while the metrics-server pod is Running and Ready. Ready means the pod’s own probe passed — it says nothing about whether kubelet scrapes are succeeding, which is the bottom hop of the diagram above.

Go straight to the logs:

kubectl logs -n kube-system -l app.kubernetes.io/name=metrics-server --tail=50

• x509: certificate signed by unknown authority → the --kubelet-insecure-tls arg is missing or did not apply. Talos kubelets present self-signed serving certs, so without that flag every scrape is rejected at the TLS handshake. It is the only arg apps/metrics-server/values.yaml sets; the building companion shows how to read the rendered arg list back and why re-declaring other flags only appends duplicates.
• unable to fully scrape metrics ... <node> for one node → that kubelet is unreachable (node NotReady, NICNetwork Interface CardThe network adapter itself. Worth naming precisely on Frank, where one flapping onboard NIC took down every pod on a node at once. flap, firewall). Cross-check kubectl get nodes and that node’s health. One bad node degrades top for that node only; the other six keep answering.
• Clean logs but top empty for ~30s after a restart → normal. The APIService reads Available=False until the first scrape window lands. Wait, do not restart — restarting resets the window and makes the wait start over.

Recover

metrics-server is stateless. Restarting is safe and loses only the in-memory scrape window, which repopulates in about 15 seconds:

kubectl rollout restart deployment metrics-server -n kube-system

That 15 seconds is --metric-resolution=15s, which comes from the chart’s defaults — apps/metrics-server/values.yaml does not set it. If you change the resolution expecting the values file to be the lever, you will be editing the wrong file.

Config changes go through git: edit apps/metrics-server/values.yaml, commit, let ArgoCD sync. The Application to sync is the leaf metrics-server, not root — the root App-of-Apps only re-templates the Application spec, while the values file is pulled by the leaf through its $values source ref. A hard refresh is a reasonable first try:

kubectl annotate application metrics-server -n argocd argocd.argoproj.io/refresh=hard --overwrite

Do not treat it as the recovery, though. Frank’s own incident record has refresh: hard failing to clear a stale Application twice in one session; what cleared both, within seconds, was an explicit sync operation. Pass syncOptions explicitly — a manually-triggered sync does not inherit spec.syncPolicy.syncOptions:

kubectl -n argocd patch application metrics-server --type=merge \
  -p '{"operation":{"sync":{"revision":"HEAD","syncOptions":["ServerSideApply=true","RespectIgnoreDifferences=true"]}}}'

metrics-server is exactly the shape most exposed to that staleness: a multi-source Application combining an upstream chart with a $values ref into this repo. So finish by asserting on the artefact rather than the tile — read the rendered args back, or re-run check 1. Synced is a claim about a comparison, not about the cluster.

Operational caveats

One replica, and it is the only aggregated API on the cluster. Two separate facts that compound. The single replica is a deliberate footprint choice recorded in the values file — metrics-server is stateless and cheaply restarted, so a brief gap is acceptable. The second fact is that v1beta1.metrics.k8s.io is the only APIService on Frank backed by a Service at all, which makes it the only one whose unavailability can slow API discovery:

$ kubectl get apiservice | grep -v Local
NAME                     SERVICE                      AVAILABLE   AGE
v1beta1.metrics.k8s.io   kube-system/metrics-server   True        9d

Every other row of kubectl get apiservice reads SERVICE: Local — served by the API server itself, with nothing to become unavailable. So if several unrelated ArgoCD apps go ComparisonError at once, check metrics-server before chasing each app individually.

Nothing pages when this layer stops working. No Grafana rule under apps/grafana-alerting/manifests/ mentions metrics-server or metrics.k8s.io, and docs/runbooks/manual-operations.yaml has no entry for it either. The building companion’s thesis is that Ready is not working; the operating consequence is that when this breaks, the things that notice are a human typing kubectl top and an HPA quietly reporting <unknown> — neither of which is a page. Until that changes, check 1 and check 3 are the monitoring.

Quick Reference

References

• Building companion: The Metrics API — the fork, the Talos flag, and the deploy-time verification path
• Operating on Green — the Synced-against-a-stale-revision incident behind the Recover section
• Issue: #394 · Deferred adapter: #701
• Gotcha: agents/rules/frank-gotchas.md → Other in-cluster apps (metrics-server / Talos); docs/runbooks/frank-gotchas/argocd.md → Synced against a stale revision
