Operating on Green

Last updated 2026-09-19

Companion to Operating on ArgoCD Drift. That post is about OutOfSync being noise — 20 of 52 apps permanently red for seven different reasons, until red meant something again. This one is the opposite failure, and the more dangerous of the two: a volume filled to 100%, a garbage collector died, and every kube_* alert rule on the cluster went blind — while every dashboard stayed green.

Nothing was misconfigured. Every limit involved was reasonable when it was set. The signals were, mostly, honest. What failed was the assumption that a green tile is a statement about the cluster.

It isn’t. A green tile is a statement about the reporter’s view of the cluster — and there are five distinct ways that view diverges from reality. Each needs a different check, and this post is those checks.

To follow along you need the ground the earlier posts built: GitOps with ArgoCD for the sync model, Observability for the VictoriaMetrics scrape path, Storage and Backups for Longhorn, and Health Bridge for how alerts become board state.

What healthy looks like

Between the thing that is true and the tile that is green sit three hops, and each one can drop the truth:

    flowchart TD
    ART["artifact<br/>status.capacity · df · exit 137"]
    REP["reporter<br/>ArgoCD · vmagent · the CronJob"]
    CON["consumer<br/>alert rule · Health Bridge"]
    TILE["green tile"]

    ART -->|"observed at all?"| REP
    REP -->|"current? right field?"| CON
    CON -->|"anyone listening?"| TILE


Ask the questions in that order and each maps to one failure class: observed at all catches out of scope, current / right field catches stale view and wrong artifact, and anyone listening catches unconsumed signal.

Five ways “green” and “true” come apart. The class determines the check — running the wrong check finds nothing and reassures you.

Only the first is the reporter being wrong. The other four are the reporter being right about something else — which is why they survive so long. The last one sits upstream of the diagram: it removes the artifact rather than losing it in transit.

Verify

Seven checks. Each is copy-pasteable, and each has a signature that distinguishes “fine” from “lying”.

1. Is the app synced to the commit you actually merged?

Synced/Healthy means live matches what ArgoCD fetched. It does not mean ArgoCD fetched your merge.

# what git says vs what the cluster holds — compare the FIELD, not the status
git rev-parse origin/main
kubectl -n <ns> get pvc <name> -o jsonpath='{.spec.resources.requests.storage}{"\n"}'

If the manifest on main says 40Gi and the live spec says 20Gi while the Application says Synced, the app is synced to an older revision. A refresh: hard annotation does not reliably clear this. An explicit sync operation does:

kubectl -n argocd patch application <app> --type=merge \
  -p '{"operation":{"sync":{"revision":"HEAD","syncOptions":["ServerSideApply=true","RespectIgnoreDifferences=true"]}}}'

Pass syncOptions explicitly — a manually-triggered sync does not inherit spec.syncPolicy.syncOptions.

Before blaming ArgoCD, rule out your own manifest. A Helm chart silently dropping an unrecognised key looks identical from the cluster:

helm template lh longhorn/longhorn --version 1.11.2 -f apps/longhorn/values.yaml \
  | grep -A5 'name: longhorn-default-setting'

If the key renders locally and is absent live while the app claims Synced, it is the sync, not the manifest.

2. Is every scrape target actually up?

This is the check that would have caught the worst of it, and almost nobody runs it. Ask the scraper, not the query engine:

VMA=$(kubectl -n monitoring get pod -o name | grep vmagent | head -1)
kubectl -n monitoring exec $VMA -c vmagent -- \
  wget -qO- 'http://127.0.0.1:8429/api/v1/targets'

The failure signature, verbatim:

kube-state-metrics  down
  the response from "http://10.244.12.41:8080/metrics" exceeds
  -promscrape.maxScrapeSize or max_scrape_size in the scrape

VictoriaMetrics discards the entire response when it exceeds the cap (16 MiB by default) — not the excess. One oversized target silently removes every series it produced. Note promscrape.streamParse being enabled does not exempt a response from the cap.

3. Do the metrics your alert rules query actually exist?

An alert rule with no data does not fire. It also does not complain.

POD=$(kubectl -n monitoring get pod -o name | grep vmsingle | head -1)
for q in kube_pod_status_ready kube_deployment_status_replicas_unavailable \
         kube_cronjob_status_last_successful_time; do
  printf '%-46s ' "$q"
  kubectl -n monitoring exec $POD -- \
    wget -qO- "http://127.0.0.1:8428/api/v1/query?query=count%28$q%29" 2>/dev/null \
    | grep -o '"[0-9]*"\]' || echo "NO SERIES"
done

Healthy output on Frank after recovery:

kube_pod_status_ready                          6405
kube_deployment_status_replicas_unavailable      75
kube_cronjob_status_last_successful_time          3

NO SERIES for any metric a rule references means that rule has been inert for as long as the series has been missing — and you cannot tell how long from the rule.

Cross-check the rules against the data, because the count is what makes this urgent:

grep -o 'kube_[a-z_]*' apps/grafana-alerting/manifests/alert-rules-cm.yaml \
  | sort | uniq -c | sort -rn

Frank had 25 references across 7 metric families — 15 of them kube_pod_status_ready — all evaluating against nothing.

4. Did that volume expansion actually happen?

Editing resources.requests.storage is accepted by the API server and by ArgoCD’s diff. Neither is evidence the volume grew.

kubectl -n <ns> get pvc <name> -o jsonpath='{.status.capacity.storage}{"\n"}'
kubectl -n <ns> exec deploy/<app> -c <container> -- df -h <mountpath>

status.capacity is the honest field, and df inside the pod is the honest-er one — a block device can grow while the filesystem does not. Longhorn refuses an expansion when the replica’s disk fails its accounting clause:

size + StorageScheduled <= (StorageMax - StorageReserved) * overProvisioning%

That clause counts each replica’s declared size, not bytes written, so a node can be half-empty and still refuse. Check headroom on the nodes that host the replicas before attempting an expansion:

kubectl -n longhorn-system get nodes.longhorn.io -o json | jq -r '
  .items[] | .metadata.name as $n |
  (.status.diskStatus | to_entries[] |
    "\($n) scheduled=\((.value.storageScheduled/1073741824)|floor)Gi " +
    "max=\((.value.storageMaximum/1073741824)|floor)Gi")'

Measured on Frank at the moment of the incident, with the ceiling at its 100% default:

node       max   reserved  scheduled    ceiling   headroom   schedulable
mini-1    929Gi    279Gi      645Gi       650Gi        5Gi      True
mini-2    929Gi    279Gi      639Gi       650Gi       11Gi      True
mini-3    929Gi    279Gi      654Gi       650Gi       -4Gi      False   <- over
gpu-1    3724Gi      0Gi      725Gi      3724Gi     2999Gi      True

Two of the three replicas of the volume being grown sat on nodes with 5Gi and −4Gi of headroom, against a 20Gi ask — while those disks were roughly 55% physically written.

5. What is running that git does not know about?

ArgoCD makes no claim about resources it does not track, and with prune: false it never will. Reading manifests cannot find these; read the cluster and filter by the tracking annotation:

kubectl -n <ns> get deploy,pvc,svc -o json | jq -r '.items[] |
  "\(.kind)/\(.metadata.name)\t\(.metadata.annotations."argocd.argoproj.io/tracking-id" // "UNTRACKED")"'

Expect legitimate hits — SOPSSecrets OPerationSMozilla's tool for encrypting the *values* in a YAML file while leaving the keys readable, so an encrypted secret still reviews as a sensible diff.-applied bootstrap Secrets and ESOExternal Secrets OperatorThe operator that pulls secrets from an external store into Kubernetes Secrets. On Frank it mints short-lived GitHub App tokens, so no long-lived credential is ever committed.-generated Secrets are untracked by design. The finding is an untracked workload or PVCPersistentVolumeClaimA Kubernetes request for durable storage. The pod names a claim and the storage layer — Longhorn on Frank — binds real disk behind it, so the data outlives the pod.. Frank had a Deployment, a Service, two Secrets and five PVCs from a migration cutover, never committed, holding 75Gi of Longhorn reservations at replicas: 0 for 18 days.

6. Is the collector actually collecting?

A CronJob that fails reports it in the only place nobody watches.

kubectl -n <ns> get cronjob <name> \
  -o custom-columns=NAME:.metadata.name,LAST:.status.lastScheduleTime,LASTOK:.status.lastSuccessfulTime
kubectl -n <ns> get jobs --no-headers | grep <name> | tail -5

A lastSuccessfulTime that lags lastScheduleTime by days is the signal. The pods are gone by then (restartPolicy: OnFailure cleans them up after the backoff), so the exit code has to be reproduced deliberately:

# same image, node, service account and limit as the CronJob — deletions stubbed
kubectl -n <ns> get pod -l job-name=<probe> \
  -o jsonpath='exit={.items[0].status.containerStatuses[0].state.terminated.exitCode} reason={.items[0].status.containerStatuses[0].state.terminated.reason}{"\n"}'
# exit=137 reason=OOMKilled

7. Will ArgoCD even apply the kinds in your manifests?

A manifest can be correct, committed, rendered and synced — and never applied. ArgoCD refuses whole kinds, before it ever reaches your object:

# the only trace: a condition on the Application, not an error
kubectl -n argocd get application <app> -o jsonpath='{.status.conditions}' | jq .

# what is excluded, live
kubectl -n argocd get cm argocd-cm -o jsonpath='{.data.resource\.exclusions}'

The failure signature, verbatim:

ExcludedResourceWarning: Resource /Endpoints victoria-metrics-victoria-metrics-k8s-stack-kube-etcd
is excluded in the settings

The argo-cd chart’s default resource.exclusions drop Endpoints and EndpointSlice for every cluster, because the control plane creates and churns those objects constantly. That default is right. It is also silent: the object renders in helm template, the sync reports success, the Application reads Synced/Healthy, and nothing is created.

Frank shipped an etcd scrape built on exactly that — a static Endpoints object pointing at the three control-plane nodes. After the merge the Service moved to its new port (Services are not excluded, so that half did apply, which is what made it look deployed) while its Endpoints stayed empty. The scrape had zero targets and stayed that way until the layer’s own absent() watchdog fired, fifteen minutes later.

Note what check 2 does here: it asks whether every scrape target is up, and finds nothing wrong, because there were no targets to be down. Each class needs its own check.

The durable fix is not to un-exclude the kind — that would make ArgoCD track every controller-managed Endpoints object on the cluster, which is the churn the default exists to avoid. Scrape host services with a VMStaticScrape or VMProbe instead, kinds ArgoCD does apply. Frank now guards this repo-wide: a tripwire parses the exclusion list out of apps/argocd/values.yaml and fails any manifest under apps/*/manifests/ whose kind ArgoCD would drop.

Recover

On Frank the retention change did the heavy lifting. Cutting TTLTime To LiveHow long a value stays valid before it must be fetched again. Sets how long a stale DNS answer or cache entry can keep being wrong after the fix. from 7 days to 3 removed 1369 of 1820 PipelineRuns in a single 100-second sweep:

pipelinerun-ttl-gc result deleted=1369 remaining=454 cutoff=2026-07-24T16:58:53Z

with these downstream effects:

Three of every four pods on the cluster were completed Tekton pods. The payload ended up under even the old 16 MiB default — so the retention cut alone would have fixed the blackout, and so would the cap raise alone. Both shipped, deliberately: alerting should not depend on a CI hygiene setting, and CI hygiene should not be load-bearing for observability.

Explanation — why green survives so long

The five classes are not five bugs. They are five places the chain from artifact to tile can break, and each one is individually defensible.

Wrong artifact is the only outright falsehood, and even it is a reasonable design. ArgoCD’s job is to make live spec match git spec; it does that, and says so. It has no opinion about whether the CSIContainer Storage InterfaceThe plugin contract for storage, the counterpart to CNI. Longhorn is Frank's CSI driver: it turns a PVC into a real replicated volume. driver honoured the request, because that isn’t its layer. The mistake is entirely on the reader who takes “the spec is applied” as “the change took effect”.

Unconsumed signal is the most common, and the most galling in hindsight. vmagent knew. It wrote the reason, in plain language, at a URL you can wget. The GC’s exit 137 sat in job status for two days. Both were honest, precise, and read by nobody — because the alerting pipeline consumes rule-evaluation severity, and neither of those is a rule.

There is a second-order version of this worth naming. Frank’s Health Bridge deliberately caps synthetic DatasourceError and NoData at degraded rather than paging, so that blindness is never mistaken for death — a good policy, written for transient datasource blips. It also, correctly by its own rules, swallowed a real and total blindness. A policy tuned for one failure mode ate a different one. That is not a bug to fix so much as a boundary to know about.

Out of scope is the quiet one. There was never a false claim about the untracked stack, because there was never a claim. It is invisible to every check that starts from the manifests, which is most of them. prune: false — the setting that makes GitOps safe to run against a cluster with hand-made bootstrap secrets — is exactly the setting that guarantees this class can never self-heal.

Stale view is the one to be humblest about. Two Applications reported Synced/Healthy against pre-merge content, minutes after their merges, and a refresh: hard did not clear either. An explicit sync did. What this post cannot tell you is why — webhook lag, poll interval, a values-ref cache — because that was never established. The recovery is known and the cause is not, and it would be dishonest to dress a procedure up as an explanation.

Never applied is the newest of the five and the hardest to see, because it breaks upstream of the diagram above. The other four assume an artifact exists to be observed, reported and consumed; this one removes the artifact. Every check that reads manifests — helm template, a CI tripwire asserting the values are right, a review of the diff — passes, because the manifests genuinely are right. The object simply never reaches the cluster, and the reporter that dropped it records a condition, not an error, on an Application that still reads Synced/Healthy.

The through-line: every one of these systems reports on its own view, faithfully. None of them is lying. The error is ours, for reading a report about a view as a report about the world.

Missteps

That last row is this post’s own thesis, arrived at while writing it. The research pass for this article was dispatched into a worktree cut from a stale local main, and reported — carefully, with citations — that none of the changes described here were present. It even noted it had found no stale-worktree explanation, which is precisely what a stale worktree cannot find from the inside. A worktree inherits the staleness of whatever it was cut from, and reports faithfully about its own view. Same class as row one.

Quick reference

Not guarded by tests. Only the PVC floor has a tripwire (scripts/tests/test_hermes_agent_shell_home_pvc.py, asserting >= 40Gi). The scrape cap, the GC memory limit, AGE_DAYS and the Longhorn ceiling are documented in comments and runbooks, not enforced in CI. And there is still no alert on PVC capacity at all — the failure that started this whole thread would, today, still happen silently.

References

• Operating on ArgoCD Drift — the false-positive counterpart
• Observability — the VictoriaMetrics scrape path, and a prior silent-drop incident (-maxLabelsPerTimeseries) of exactly this family
• Storage and Backups — Longhorn replica scheduling
• Health Bridge — why NoData caps at degraded
• CI on the Mirrors — the growth curve behind the object count
• agents/rules/frank-gotchas.md and docs/runbooks/frank-gotchas/{argocd,storage-secrets-ssa}.md — the durable one-liners and full recovery prose
