Self-Hosted Inference & the LLM Gateway Pattern

TL;DR

Inference is a build-versus-buy question dressed up in GPU language. The engine tier (Ollama, vLLM, llama.cpp, TGI) decides whether the model runs on your metal; the gateway tier (LiteLLM, OpenRouter) decides whether anything sits in front of the engine. The two decisions are independent.

Frank’s stack is Ollama on a 16GB RTX 5070 Ti behind LiteLLM at 192.168.55.206. The honest costs: qwen-vl-7b dropped from q8_0 to Q4_K_M for the VRAM ceiling; LiteLLM’s OSS image emits no litellm_* Prometheus metrics (Enterprise-only); OLLAMA_KEEP_ALIVE pinned the container cgroup RAM and looked like a VRAM bug for hours.

This stack wins on data-locality, latency floor, and learning depth. On every other axis a hosted API behind LiteLLM is the right answer for most teams — see §6.

§1 — The capability

The question I had to answer on Layer 10 was the same question every team who has ever wanted to run an LLM has had to answer: where does inference live? In the cluster I am, in someone else’s datacenter, or in some combination of both? It is a build-versus-buy question dressed up in GPU language, and the answer determines everything downstream — latency floor, data-locality posture, monthly bill, who gets paged at 3 AM when the endpoint returns 503.

    flowchart LR
    App["Application<br/>(chat UI, agent,<br/>batch job)"] --> GW["Gateway<br/>(LiteLLM,<br/>OpenRouter)"]
    GW --> E1["Self-hosted engine<br/>(Ollama / vLLM /<br/>llama.cpp / TGI)"]
    GW --> E2["Hosted API<br/>(OpenAI / Anthropic /<br/>Groq / Together)"]
    E1 --> HW["Local GPU<br/>(RTX 5070 Ti, 16GB)"]
    E2 --> Net[("Internet")]


Look at the diagram and notice the two seams. The first seam is between the application and the gateway: somebody, somewhere, has to translate “give me a chat completion” into an HTTP call. The second seam is between the gateway and the engine: that HTTP call resolves either to a process I control on the metal next to me, or to a packet leaving my switch.

Every stack owner makes two decisions here:

1. Which engine runs the model? Self-hosted (Ollama, vLLM, llama.cpp, TGI) or hosted (OpenAI, Anthropic, the rest of the API zoo).
2. Does anything sit in front of the engine — a gateway? And if so, which one, and what does it do that the engine doesn’t?

The two decisions are independent. You can self-host the engine and skip the gateway. You can use a hosted API and still put a gateway in front of it for cost tracking. You can run both engines simultaneously and have the gateway route. The rest of this paper is about why those four cells exist and which one I ended up in.

§2 — The landscape

The OSS / self-hostable inference space has two tiers — engine and gateway — and the same vendor table tells both stories.

quadrantChart

    title Self-hosted inference landscape — 2026
    x-axis "Engine layer" --> "Gateway layer"
    y-axis "Single machine" --> "Cluster-scale / multi-tenant"
    quadrant-1 "Cluster-scale gateways"
    quadrant-2 "Cluster-scale engines"
    quadrant-3 "Single-machine engines"
    quadrant-4 "Single-machine gateways"
    "Ollama": [0.15, 0.20]
    "llama.cpp": [0.05, 0.15]
    "vLLM": [0.20, 0.85]
    "TGI": [0.25, 0.80]
    "LiteLLM": [0.75, 0.78]
    "OpenRouter": [0.95, 0.90]



The four engines fan out across the cost-vs-throughput trade. Ollama is the single-binary entry point — a Modelfile abstraction over llama.cpp plus GGUF, optimised for “I want a chat endpoint on my laptop, now.” Its sibling llama.cpp lives even further to the leftmost floor: pure-C, CPU-only-possible, runs on a Raspberry Pi as gracefully as on a workstation. At the cluster-scale end, vLLM is what most of the commercial inference SaaS providers actually run under the hood — its block-allocated KV cache (PagedAttention) is the load-bearing reason it handles concurrent users gracefully. TGI is HuggingFace’s production-grade serving stack — continuous batching, tensor parallelism, more knobs than Ollama, more operational complexity than vLLM.

Two-to-four-times throughput at equal latency is what makes vLLM structurally different from Ollama — it isn’t just a faster implementation, it is a different algorithm for managing GPU memory under contention.

At the gateway tier the split is sharper. LiteLLM is the OSS gateway: virtual keys, OpenAI-compatible routing, cost ledger, ~100 upstream provider integrations. OpenRouter is the same shape sold as a managed service — pay-per-token, no infra to run, frontier-model coverage by default. If you only ever talk to hosted APIs, OpenRouter eats LiteLLM’s lunch on operational simplicity. If you self-host engines, LiteLLM is the only gateway that speaks both worlds.

Legend: ✅ supports the feature in OSS form, 🟡 partial, ❌ not in OSS, n/a where the feature doesn’t apply (gateways don’t run weights). The LiteLLM row’s prometheus_metrics: ❌ is the load-bearing cell — see §5.

The gateway-tier vendors converge on the OpenAI HTTP shape, because every upstream provider does. The engine-tier vendors converge on GGUF + the OpenAI HTTP shape — except for vLLM and TGI, where GGUF support is partial because their throughput story is built on different memory layouts.

§3 — How each option handles the hard part

The hard part for an inference engine is keeping the GPU busy without losing the KV cache between requests. The hard part for a gateway is being honest about what it does and doesn’t observe. Both problems have textbook answers; both have problems that show up only when you wire them into a real cluster.

Ollama — single-user-first, hide the llama.cpp

    flowchart TD
    Req["OpenAI-shaped<br/>request"] --> API["Ollama HTTP API<br/>(:11434)"]
    API --> Sched["Sequential<br/>scheduler"]
    Sched --> KV["KV cache<br/>(per session)"]
    KV --> Run["llama.cpp runtime<br/>+ GGUF weights"]
    Run --> GPU["GPU memory<br/>(model + KV)"]
    Run --> PageCache[("Page cache<br/>OLLAMA_KEEP_ALIVE")]


Ollama hides every interesting decision behind a Modelfile and an HTTP endpoint that mimics OpenAI’s. Underneath, it is llama.cpp wearing a friendlier name — same GGUF quantization, same CPU-fallback story. The scheduler is sequential by default; multi-user throughput depends on session isolation rather than batching. For ≤2 concurrent users this is indistinguishable from vLLM in subjective feel. Push it to 8 concurrent chat sessions and the difference appears as latency tail.

The foot-gun is OLLAMA_KEEP_ALIVE. Setting it to 24h keeps the model weights resident in memory across requests — fantastic for first-token latency on the next request, terrible if the container’s resources.limits.memory is tight, because the page-cache fills until the cgroup ceiling and Ollama starts emitting “system memory” errors that read like VRAM exhaustion. The incident below is mine.

vLLM + PagedAttention — block-allocate the KV cache

    flowchart TD
    Req2["OpenAI-shaped<br/>request"] --> API2["vLLM HTTP API<br/>(:8000)"]
    API2 --> CBatch["Continuous<br/>batching scheduler"]
    CBatch --> Paged["PagedAttention<br/>block table"]
    Paged --> KV2["KV cache blocks<br/>(non-contiguous)"]
    KV2 --> Engine2["vLLM runtime<br/>(CUDA kernels)"]
    Engine2 --> GPU2["GPU memory<br/>(blocks + weights)"]


vLLM treats the KV cache the way an operating system treats RAM — fixed-size blocks, a page table, copy-on-write across prefix-sharing requests. The continuous-batching scheduler can append a new request’s tokens to an in-flight batch without waiting for the current step to finish, which is where the 2–4× throughput comes from at >1 concurrent user. If your workload is “five chat sessions and a batch summarisation job hitting the same model”, vLLM is the right answer and Ollama is not.

The cost is operational: vLLM is not a single binary, GGUF support is partial, and the supported-model surface lags the latest community releases by a release cycle.

llama.cpp / llama-server — the OSS floor

    flowchart TD
    Req3["OpenAI-shaped<br/>request"] --> Srv["llama-server<br/>(:8080)"]
    Srv --> CSched["C scheduler<br/>(per-slot)"]
    CSched --> CKV["KV cache<br/>(per slot)"]
    CKV --> Cpp["llama.cpp runtime<br/>+ GGUF"]
    Cpp --> CPUorGPU["CPU or<br/>partial-offload GPU"]


llama.cpp is the engine all the others borrow from. Pure C, no Python runtime, builds on a Pi. llama-server exposes an OpenAI-compatible endpoint with a slot-based scheduler. If you are running on hardware where Ollama feels overweight — embedded boxes, Raspberry Pis, a laptop without a GPU — this is the floor.

TGI — production-grade transformer serving

    flowchart TD
    Req4["OpenAI-shaped<br/>request"] --> Router["TGI router<br/>(:80)"]
    Router --> Batcher["Continuous<br/>batcher"]
    Batcher --> Shard["Tensor-parallel<br/>shards (n)"]
    Shard --> GPUs["Multi-GPU<br/>(NVIDIA / AMD)"]


TGI is what HuggingFace ships to companies that want to run their own models at production scale without writing the serving layer. Continuous batching, tensor parallelism, Prometheus metrics in OSS — the trade is the operational complexity (container image is heavy, supported-model list is opinionated). For a single-GPU homelab it is overkill; for a four-GPU node serving a real product it is appropriate.

LiteLLM — the OSS gateway

    flowchart TD
    Caller["Application<br/>OpenAI SDK"] --> LL["LiteLLM proxy<br/>(:4000)"]
    LL --> VK["Virtual keys<br/>+ budget ledger"]
    LL --> Route["Router<br/>(model → upstream)"]
    Route --> Local["Local engine<br/>(Ollama on gpu-1)"]
    Route --> Hosted["Hosted APIs<br/>(OpenAI, Anthropic, …)"]
    LL --> Logs[("Access logs<br/>+ DB ledger")]


LiteLLM is the gateway shape Frank lives behind: virtual keys per consumer, a cost ledger that survives upstream price changes, model aliases mapped to upstream engines, OpenAI-compatible HTTP at every consumer endpoint. The clever part is that the upstream pool is a flat namespace — gpt-4o, ollama/llama3:8b, claude-3-5-sonnet, all addressable by alias from the same key — so application code never learns where the model actually runs. The dishonest-by-omission part is the metrics tier (see §5).

OpenRouter — the gateway sold as a service

    flowchart TD
    Caller2["Application<br/>OpenAI SDK"] --> OR["OpenRouter<br/>(api.openrouter.ai)"]
    OR --> Auth["API key<br/>+ usage ledger"]
    OR --> Pool["Provider pool<br/>(100+ models)"]
    Pool --> P1[("Anthropic")]
    Pool --> P2[("OpenAI")]
    Pool --> P3[("Together, Groq,<br/>DeepSeek, …")]


Same gateway shape, opposite operational model. OpenRouter aggregates hosted providers behind a single OpenAI-compatible endpoint; you pay for tokens, not for the gateway. If your stack is all hosted, OpenRouter is strictly easier than running LiteLLM. If your stack has even one self-hosted engine, OpenRouter cannot route to it and LiteLLM is the only gateway that closes the loop.

§4 — What scale changes

At one user and one conversation, all four engines look identical. Token latency is dominated by the model size and the GPU’s memory bandwidth; the scheduler barely matters. Scale changes everything.

Continuous batching dominates at >2 concurrent users. The vLLM team’s own measurements pin this clearly:

The numbers come from datacenter GPUs (H100, A100) under ShareGPT — a benchmark designed to stress concurrent multi-turn workloads. They do not translate cleanly to a 16GB consumer GPU at 2 concurrent users. The direction generalises (vLLM > Ollama under concurrency); the magnitude does not. This is the unfilled gap in the literature — nobody has published a head-to-head latency-and-cost benchmark for Ollama vs vLLM vs llama.cpp at homelab scale on a single consumer card. I have not run one myself. I should.

VRAM is the binding constraint, and quantisation is the model-quality knob. A 16GB GDDR7 budget on the RTX 5070 Ti will not fit qwen-vl-7b at q8_0 plus a reasonable context window plus the KV cache plus the page cache. So qwen-vl-7b drops to Q4_K_M. That is a model-quality decision disguised as a performance one — measured perplexity climbs, downstream accuracy degrades on long-context tasks, and the workaround belongs in §6’s “doesn’t generalise” list rather than the §5 story. Datacenter H100s do not have this problem.

Gateway features become non-negotiable at ≥2 applications sharing an engine. When the only consumer is your laptop, the gateway is friction. When two applications, one cron job, and an autonomous agent all want the same llama3:8b, virtual keys and a cost ledger are the only thing between you and a per-consumer attribution mess. The gateway tax pays itself back fastest in a multi-tenant cluster — which is exactly the direction Frank is heading.

§5 — Frank’s choice, and what happened

Frank’s stack is Ollama on gpu-1 (RTX 5070 Ti, 16GB GDDR7) behind LiteLLM at 192.168.55.206. The combination wasn’t an optimum — it was a sequence. Ollama came first because it ran on the laptop already; LiteLLM came second because the second consumer (an agent, not a chat UI) needed a virtual key. By the time the third consumer arrived, the gateway was load-bearing and swapping the engine became expensive.

I will defend the choice on three axes only — data-locality, latency floor, learning depth — and I will be honest that on every other axis a hosted API behind LiteLLM is the more sensible answer for most teams. The scars below are the receipts.

Three real incidents, three real dates, all reachable from the gotchas registry. None of them are mistakes a hosted API behind OpenRouter would have produced. All of them taught more than the equivalent green checks on a managed dashboard would have.

§6 — When Frank’s answer doesn’t generalize

I am Frank, a single-operator learning platform with one consumer GPU. My stack is not the right answer for any team that has even two of those attributes inverted.

    flowchart TD
    A["Need data-locality<br/>(prompt cannot<br/>leave network)?"] -- "Yes" --> B["Multi-user<br/>or batched workload?"]
    A -- "No" --> L1["Cloud API behind<br/>LiteLLM<br/>(privacy-aware routing)"]
    B -- "No" --> L2["Ollama + LiteLLM<br/>on a single GPU<br/>(Frank today)"]
    B -- "Yes" --> L3["vLLM/TGI on<br/>dedicated GPUs,<br/>LiteLLM as gateway"]


The four-leaf decision tree captures the honest answer set. Frank is at L2: data-locality matters because the agents handle private repo contents, multi-user demand is below the threshold that justifies vLLM’s operational tax, and the budget is “one GPU.” Most teams should be at L1 — privacy-aware routing through LiteLLM in front of OpenAI and Anthropic, no engines to operate. Production teams running OSS models at scale should be at L3, where vLLM’s PagedAttention earns the operational complexity.

The one cell missing from the tree is “use OpenRouter alone.” It is a real answer; it didn’t survive the data-locality branch because OpenRouter cannot route to a self-hosted engine. If your stack is all hosted, OpenRouter is strictly simpler than LiteLLM, and the absence above is about the data-locality question, not OpenRouter’s quality.

§7 — Roadmap & where this space is going

Three trends will reshape this landscape by the end of 2026.

Engine convergence on the OpenAI HTTP shape. Every engine in the matrix already speaks OpenAI-compatible HTTP. By next year the small remaining gaps (function-calling extensions, structured-output schemas) will close, and gateway routing becomes mostly free. The benefit accrues to LiteLLM and OpenRouter equally; the engines stop being differentiated on protocol and start being differentiated only on throughput-per-watt.

Cost ledgering becomes table-stakes for gateways. LiteLLM, Helicone, Pezzo, and a handful of internal-built gateways are converging on the same feature set: per-key budgets, per-model unit cost, audit trails. The managed-vs-OSS gap is mostly about Prometheus metrics today — that gap will narrow because the OSS community will route around it (Frank’s plan is to synthesise gateway metrics from LiteLLM access logs, which the gotchas registry calls out as the obvious workaround).

The Enterprise/OSS split stays live. LiteLLM’s metrics-tier gap is not a bug — it is a business model. Expect more “the docs mention this quietly but the marketing doesn’t” footnotes as OSS gateways monetise around observability rather than the proxy itself. Read the virtual-keys page closely.

Frank’s roadmap: add vLLM alongside Ollama on gpu-1 for the batched-workload case (Layer 23-ish), explore Prometheus signal synthesis from the gateway’s own access logs to close the OSS-tier observability gap, and — eventually — re-run the head-to-head small-scale benchmark that the literature has not yet published. The dossier names that gap; it is mine to either fill or admit I never filled.
