Edge Clusters & Public Exposure

TL;DR

Public exposure from a home cluster is a five-job problem: NAT traversal, TLS termination, DNS, reverse proxy, mesh coordination. The 2026 vendor space splits on one question — cede the edge to someone else (Cloudflare Tunnel, Tailscale Funnel, ngrok) or run your own (tiny VPS with Headscale

• Caddy, or a multi-region cluster with Rancher Fleet).

Frank runs the middle path: a single-node Talos cluster called Hop on a Hetzner CX23 (~€5/month), Caddy on hostPort 80/443 terminating TLS via Cloudflare DNS-01, Headscale as mesh control plane. The scars: hostPort

• RollingUpdate deadlocks, a Headplane v0.5 rewrite that silently dropped env-var config, Tailscale needing kernel mode for source-IP visibility.

Frank’s answer doesn’t generalize. One blog → Cloudflare Tunnel. Three-plus clusters → Rancher Fleet. Frank picked Hop because the Headscale control plane lives there — putting it behind someone else’s tunnel re-creates the chicken-and-egg.

§1 — The capability

Frank lives behind a residential ISP. There is no static IPv4 address, there may be CG-NAT, and inbound 80/443 is at the discretion of a router nobody is paying for. A subset of Frank’s services need to be reachable from the open internet anyway: the Hugo blog at blog.derio.net/frank, the Headscale coordination server at headscale.hop.derio.net, the private landing page that’s only reachable over the mesh, and — as the agentic side of the story matures — webhook endpoints for GitHub events routed back into in-cluster Tekton listeners.

That is the capability under examination. Not “exposing a service” in the abstract — any tunnel does that — but what sits at the edge between the residential ISP and the cluster, who terminates TLS, and where does the auth boundary live? The edge is doing five jobs simultaneously: NAT traversal (because residential inbound is dying as IPv4 exhausts), TLS termination (because everything is HTTPS), DNS and domains (because people don’t type IP addresses), reverse proxy (because one IP serves many services), and — when the mesh model is in play — mesh coordination (the control plane that tells nodes how to find each other).

    flowchart LR
    U["Public internet"] --> E["Edge (someone's)"]
    E --> NAT["NAT traversal"]
    E --> TLS["TLS termination"]
    E --> DNS["DNS / domains"]
    E --> RP["Reverse proxy"]
    E --> MC["Mesh coordination"]
    E --> H["Home cluster"]
    H -.-> ISP["Residential ISP (no inbound)"]


The vendor space splits on a single structural question: do you cede those five jobs to someone else’s edge (Cloudflare Tunnel, Tailscale Funnel, ngrok), or do you run your own edge node — a tiny VPS, a real Kubernetes cluster, or a managed multi-region fleet? Both answers are defensible. The §6 decision tree exists because pretending Frank’s separate-VPS-cluster path is the One True Path would be dishonest. For a homelab whose only public surface is a static blog, “just put it behind Cloudflare Tunnel” is the correct answer, and the rest of this paper is about when that answer stops being correct.

§2 — The landscape

Two axes carve up the 2026 edge-exposure space. The horizontal axis is who owns the edge node: on the left, you cede the edge to a vendor’s network (Cloudflare’s 337-city PoP mesh, Tailscale’s coordination plane, ngrok’s regional gateways); on the right, you run the edge yourself, on infrastructure you pay for and patch. The vertical axis is data-plane shape: at the bottom, classic hub-and-spoke tunnels where the edge is the single ingestion point; at the top, mesh overlays where every node is a peer and the “edge” is just another tailnet member that happens to also be reachable from the public internet.

quadrantChart

        title Edge & public exposure — 2026
        x-axis "Vendor-owned edge" --> "Dedicated edge node"
        y-axis "Hub-and-spoke" --> "Mesh overlay"
        quadrant-1 "Dedicated · Mesh"
        quadrant-2 "Vendor-edge · Mesh"
        quadrant-3 "Vendor-edge · Hub-and-spoke"
        quadrant-4 "Dedicated · Hub-and-spoke"
        "Cloudflare Tunnel": [0.10, 0.20]
        "Tailscale Funnel": [0.20, 0.85]
        "ngrok": [0.10, 0.15]
        "Headscale + tiny VPS": [0.80, 0.75]
        "Multi-region cluster": [0.95, 0.30]



The matrix grades the five options on whether you need to run an edge node at all, whether a free tier is viable for real use, who terminates TLS, whether the option survives CG-NAT, whether you can bring your own domain, whether the data plane is mesh-shaped, whether the option is OSS without a contract, and whether you own the data plane end-to-end. The “you own the data plane” column does most of the work — every other column is either always-yes or differs by one row.

Cloudflare Tunnel optimises for zero edge infrastructure. The cloudflared daemon dials out from inside the cluster, Cloudflare’s edge serves the public hostname, the free tier covers most homelab volumes, and you get a TLS cert without touching ACME. The trade — which Cloudflare names in its own documentation — is that TLS is terminated at Cloudflare’s edge:

That outbound-only posture is the headline feature; the corollary is that Cloudflare is positioned to decrypt every byte that flows through your tunnel. For a public blog, fine. For Headscale coordination traffic or agent SSH sessions, a different conversation.

Tailscale Funnel is the same five-job bundle delivered through the mesh. Your node is on the tailnet anyway; Funnel says “also accept public traffic on a Tailscale-issued subdomain, terminate TLS on the device itself, and forward to a local service.” Custom domains are landing in pieces — at time of writing, the Tailscale-issued *.ts.net subdomain is the canonical path, and BYO-domain Funnel support varies by plan and feature flag.

ngrok is the original dev-tunnel grown into a “universal gateway” brand. Outbound-initiated, ephemeral or reserved domain, OAuth and IP allowlisting on paid plans. The free tier is real but tight enough that production use means a paid plan.

Headscale + tiny VPS is the most-work, most-ownership answer. Headscale is the self-hosted Tailscale control server; pair it with Caddy as the reverse proxy and TLS terminator and you have a complete edge that uses standard primitives end-to-end. Your DNS, your TLS keys, your data plane. The cost is the VPS itself — Frank pays ~€5 a month for a Hetzner CX23 — and the operational scars of running a single-node cluster as load-bearing infrastructure.

Multi-region cluster (Rancher Fleet) is the enterprise heavyweight. Same shape as Headscale + tiny VPS but with multiple edge regions, a unified GitOps surface, and an operations team. Below three managed clusters it’s overhead; above three it starts paying for itself.

§3 — How each option handles the hard part

The hard part is getting a packet from the public internet to a Service inside a home cluster, with TLS terminated by someone authorised to terminate TLS for your domain, and an audit trail of who did what when. Five vendors collapse into three architectural shapes. Paper 20 lays out one flowchart TD per shape, in a shared visual language: rectangles are servers and Pods, dashed edges are control-plane paths, solid edges are data-plane paths, cylinders are persistent storage.

Shape A — tunnel-back-to-origin (Cloudflare Tunnel; ngrok takes the same shape, with ngrok’s regional gateways playing the role of Cloudflare’s edge PoPs). A daemon inside the cluster dials out to the vendor’s network and holds the connection open. The vendor’s edge takes the public TLS connection, decrypts it, and forwards the cleartext request back through the tunnel to the origin.

    flowchart TD
    U["Public internet"] --> CF["Cloudflare edge PoP"]
    CF -- "TLS terminated here" --> TUN["cloudflared (outbound-initiated tunnel)"]
    TUN --> POD["Pod in home cluster"]
    CF -.-> CTRL[("Cloudflare control plane")]
    TUN -.-> CTRL


At runtime, the cloudflared process holds an outbound TCP connection to the nearest Cloudflare PoP. The PoP terminates TLS with a cert issued by Cloudflare’s CA for the hostname you registered. Failure mode: if the tunnel daemon dies, your domain stays up but is unreachable until cloudflared reconnects — typically seconds. If Cloudflare’s edge dies, the same. Blast radius is bounded to “whatever traffic was in flight”; the cluster itself is unaffected. ngrok is architecturally identical with a different vendor name on the PoP box and different SLAs.

Shape B — mesh-overlay-as-edge (Tailscale Funnel). TLS terminates on the node itself, not on the vendor’s edge. Tailscale runs a TCP proxy at its edge that proxies inbound TCP to a tailnet IP; the Tailscale daemon on your device terminates the TLS connection and forwards to a local service.

    flowchart TD
    U["Public internet"] --> TS["Tailscale Funnel TCP proxy"]
    TS --> NODE["Tailnet node (Tailscale daemon)"]
    NODE -- "TLS terminated here" --> POD["Application Pod"]
    TS -.-> CTRL[("Tailscale control plane")]
    NODE -.-> CTRL


That is the architectural twin of Frank’s choice — TLS terminates on infrastructure you control — but the coordination plane is still Tailscale’s. Failure modes: the Funnel TCP proxy dies, all Funnel- exposed services go dark; the Tailscale control plane is unreachable, new connections may fail but existing tunnels usually keep working.

Shape C — dedicated-edge-cluster (Frank: Headscale + Caddy on Hop; the multi-region cluster pattern with Rancher Fleet is the same shape scaled up, with one Caddy-equivalent per region and Fleet doing the GitOps sync across them). The edge IS a cluster you run. Caddy binds hostPort 80/443 on the node, terminates TLS with certs issued via Cloudflare DNS-01 (because there’s no HTTP-01 path through a Hetzner public IP without a domain on it first), and reverse-proxies to Services in the same cluster. Headscale runs as a Pod in the same cluster and is itself one of the services Caddy fronts.

    flowchart TD
    U["Public internet"] --> CADDY["Caddy (hostPort 80/443)"]
    CADDY -- "TLS terminated here (Cloudflare DNS-01)" --> SVC["Hop Service"]
    SVC --> HS["Headscale Pod"]
    SVC --> BLOG["Blog Pod"]
    U2["Mesh client (laptop, phone)"] --> TSD["Tailscale DaemonSet on hop-1"]
    TSD --> HS
    TSD -.-> CADDY
    HS -.-> CERTS[("Hetzner Volume: certs, headscale.db")]
    CADDY -.-> CERTS


At runtime, Caddy holds the only listeners on 80/443. The Tailscale DaemonSet on hop-1 runs in kernel mode with hostNetwork — without that, Caddy would see every mesh request as coming from 127.0.0.1 and the “mesh-only services” boundary would collapse. Headscale persists its SQLite DB and ACL config to a Hetzner Volume mounted at a fixed path. Failure mode: hop-1 itself goes down and everything Hop serves — public blog, Headscale control plane, mesh-only landing page — goes down with it. This is the single-node-cluster blast radius made concrete, and it is the price of admission for owning the data plane.

The inlets.dev project occupies an interesting middle position between Shapes A and C: you still run a VPS, but only the tunnel daemon on it, not a coordination server or a cluster. For a team that wants self-hosted tunneling without taking on a Kubernetes control plane at the edge, it is a defensible choice; Frank chose the heavier path specifically because the Headscale control plane needed somewhere to live anyway.

§4 — What scale changes

Three scale axes flip the ranking. The first is tunnel concurrency. Free-tier tunnels (Cloudflare, ngrok) cap connection count and request rate at numbers that comfortably serve a static blog and start to bind around the hundred-concurrent-connections mark. Cloudflare’s free Tunnel limits are generous-but-real; ngrok’s free tier is openly tighter and the paid plans exist for exactly this reason. Above roughly a hundred concurrent connections — say, an agent control plane that opens long-lived SSE streams to every dashboard tab — the calculus changes and either you pay or you move off the SaaS edge.

The second axis is mesh peer fan-out. Tailscale’s mesh is free up to the current TOS threshold (in the low-three-digit node count, subject to change), then priced per seat. Headscale is uncapped because you run it; the cost is operating it. The node-count knob also costs CPU on the coordination server — every node that joins generates key exchanges, ACL evaluations, and DERP heartbeats. Frank’s Hop runs on a 2-vCPU Hetzner CX23, which is comfortable for the current tailnet of under thirty nodes and would start tightening somewhere north of a hundred.

The third axis is single-node blast radius. When the edge IS the cluster (Frank’s Hop), a single-node failure takes down everything simultaneously: the public blog, the Headscale coordination plane, the private landing page, the mesh-only DNS entries that depend on Hop’s MagicDNS. The Shape A vendors fail differently — your origin keeps running, the tunnel daemon will reconnect, and the failure surface is “the tunnel itself,” for which Cloudflare’s “tunnel healthy” dashboard is the only signal. Cloudflare’s network claim sets the baseline:

A single Hetzner Falkenstein PoP cannot match that. Hop trades geography for ownership. A reader in Sydney is dramatically closer to Cloudflare’s Sydney PoP than to Frank’s Falkenstein VPS, and that latency tax is real. Frank pays it because the Hop cluster is also the Headscale coordination plane, and ceding the mesh control plane to a vendor edge would re-create a chicken-and-egg the cluster works hard to avoid: the mesh data plane depending on the mesh control plane being reachable through the mesh.

§5 — Frank’s choice, and what happened

Frank chose Headscale + Caddy + Hugo blog + private landing page, all running on a single-node Talos cluster called Hop, provisioned on a Hetzner CX23 at €5/month including the Hetzner Volume. The full chain: Packer builds a Hetzner Cloud snapshot from the upstream Talos hcloud-amd64.raw.xz; hcloud server create provisions the VPS and attaches the Volume; talosctl apply-config + talosctl bootstrap brings up the single-node cluster (the control-plane taint removed because the same node has to also schedule workloads); ArgoCD on Hop syncs the app-of-apps from clusters/hop/apps/; Caddy on hostPort 80/443 terminates TLS via Cloudflare DNS-01; Headscale coordinates the mesh; Tailscale DaemonSet on hop-1 gives the node a tailnet IP so Caddy sees mesh source IPs. The Hugo blog is baked into a Caddy-compatible container and served at blog.derio.net/frank.

That sentence took three weeks. The scars came in the seams.

There are quieter scars too — the talosctl apply-config --config-patch flag that patches the on-disk base file rather than the running cluster config, so a missed patch silently loses the change at the next reboot; the Talos control-plane taint that has to be removed for any workload to schedule on a single-node cluster; the PodSecurity namespace labels (pod-security.kubernetes.io/enforce: privileged) required for the hostPort/privileged combination Caddy and Tailscale demand. None are bugs in any one component. All are properties of the edge model, and all are documented in agents/rules/hop-gotchas.md because the next person to set this up (or the next Hop rebuild) will hit them again.

§6 — When Frank’s answer doesn’t generalize

The decision turns on three questions: how many services and how stateful are they, are you already on a mesh, and do you need to own the data plane end-to-end? Four leaves cover most of the homelab-to-small-enterprise space:

    flowchart TD
    A["Only need to expose 1–2 stateless services (blog, status page)?"] -- "Yes" --> L1["Cloudflare Tunnel"]
    A -- "No" --> B["Already on Tailscale / want exposure as a side effect of mesh?"]
    B -- "Yes" --> L2["Tailscale Funnel"]
    B -- "No" --> C["Need full data-plane ownership + your own DNS + self-terminated TLS?"]
    C -- "Yes" --> L3["Headscale + tiny VPS (Frank)"]
    C -- "No, multi-region + ops team" --> L4["Multi-region cluster (Rancher Fleet)"]


The Cloudflare Tunnel leaf is the correct answer for a lot of homelabs. If your only public surface is a Hugo blog and a Grafana dashboard you share with three friends, the math on running a separate VPS cluster is bad: you trade a five-minute setup for three weeks of hostPort + RollingUpdate scars. The Tailscale Funnel leaf is the correct answer for teams already deep in the tailnet — Funnel is one toggle and inherits the mesh’s auth model for free. The Rancher Fleet leaf is correct above the three-cluster threshold, where one logical GitOps surface spanning hub + edge + cloud actually saves more operational time than it costs to set up. Frank’s Hop leaf is correct specifically because the Headscale coordination plane lives there, and the alternative — Cloudflare Tunnel in front of the Headscale Pod — re-creates the chicken-and-egg that the mesh model exists to avoid.

What this tree does not say: it does not say one leaf is “more sophisticated” than another. The right answer for a regulated enterprise with three EU regions and a security team that has opinions about TLS termination is a multi-region cluster with Fleet regardless of how cool a tiny self-hosted VPS sounds, and a homelab whose only public surface is a static blog should pick the five-minute path and not feel apologetic about it.

§7 — Roadmap & where this space is going

Three trends worth naming. First, CG-NAT keeps eating IPv4 inbound. Residential ISPs continue rolling out carrier-grade NAT as the IPv4 exhaustion workaround, which means “port-forward 443” is dying as a homelab option faster than IPv6 is replacing it for consumer-grade inbound. Tunnels and mesh overlays are not optional features — they are the default path forward. This raises the floor for “I want to expose one service” and makes the “no edge node” tier of the vendor space more important, not less.

Second, Tailscale Funnel with first-class custom-domain support is closing the gap with dedicated edges. When Funnel can serve blog.your-domain.tld with a self-supplied TLS cert and a real ACME flow without a third-party intermediary, the architectural gap between “managed-mesh-as-edge” and “dedicated edge cluster” narrows to “do you trust Tailscale’s TCP proxy with your TLS.” Watch the next twelve months of the Tailscale roadmap. If BYO-domain Funnel lands GA at a price that undercuts a Hetzner CX23 plus the operational overhead of running it, the Frank-style edge cluster has to justify itself differently than it does today.

Third, edge clusters are becoming agentic landing pads. When a home cluster grows agents that need a public callback URL — webhooks, OAuth redirects, Tekton EventListeners receiving GitHub events — the edge cluster stops being “the thing serving the blog” and becomes “the thing the public internet talks to when an agent needs a reply.” Hop is already being asked to do that double duty: the GitHub webhook receiver Frank uses for Tekton-triggered pipelines lands at a Hop-fronted URL and is proxied back across the mesh to a Frank Service. Expect the single-node CX23 answer to strain, and expect the dedicated-edge-cluster pattern to either grow legs (more CPU, more storage) or split into two — a public-facing edge cluster and a separate mesh-coordination cluster — once the agentic workload shape stops fitting on one VPS.
